PSSO K-215CM 2-Way Coaxial Wedge 400W

PSSO

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for PSSO K-215CM 2-Way Coaxial Wedge 400W

Info
order code
11041119
product link
EAN
4026397516340
Product Name
PSSO K-215CM 2-Way Coaxial Wedge 400W
technical overview
Components: 38 cm woofer (15"), 2.5 cm horn (1")
Connection: 2 x Speakon
Sensitivity: 99 dB
Maximum SPL: 131 dB
Impedance: 8 ohms
Crossover frequency: 1.5 kHz
Dispersion angle: 70° x 70°
Dimensions (H x W x D): 352 x 580 x 502 mm
Weight: 25 kg
Size of woofer: (15") ca. 38 cm
Rated power: 400 W RMS
Program power: 800 W
Frequency range: 58 - 19000 Hz
Height: 35,2 cm
Depth: 50,2 cm
Width: 58 cm
Impedance: 8 Ohm
main features
Pro PA speaker, 15" woofer, 1.4" horn, 400 W RMS / 8 ohms
-Rugged 2-way coaxial wedge, qualified for touring applications
-Housing made of 15 mm birch plywood
-38 cm (15") bass speaker with diecast aluminum basket
-36 mm horn tweeter (2.8", 72 mm voice coil)
-Premium custom-made drivers by European manufacturer CELTO Acoustique
-Permium passive 2-way crossover
-Bassreflex system
-Parallel Neutrik Speakon connectors
-Scratch-resistant lacquer surface
-Impact-resistant steel grille with acoustic foam
-Flange for stand installation
-Applications: standing, on a subwoofer or speaker stand, suspended, and as sidefill
Audio
Frequency response, from
58 Hz
Frequency response, to
19000 Hz
impedance
8 ohm
Electrical
power consumption watt, max
400.00 W
Mechanical
weight
25.00 kg
width
580.00 mm
height
352.00 mm
length
502.00 mm
