Produktdetails: Truss HOFKON 290-4 100cm -

Hersteller

Brookstrasse 8
49497 Mettingen

4-point truss, incl. Conical connectors

Info
short summary	4-point truss, incl. Conical connectors
product description	TECHNISCHE DATEN: Traversenmaß: 290 x 290 mm Traversenlänge: 1000 mm Gurtrohr: 50 x 2 mm Fachwerk: 20 x 2 mm Legierung: EN AW 6082 T6 EUROCODE 9 geprüft TÜV geprüfter Betrieb inkl. Verbinderset (4x Konusverbinder, 8x Trusspin, 8x Federstecker) Maße: 290 x 290 x 1000 mm Gewicht: 5,6 kg Pulverbeschichtung möglich The standard truss -size in the world of trusses is HOFKON 290-4. Lightness and flexibility are the main characteristics of HOFKON 290-4 series. Its conical connection secures a fast and safe assembly. HOFKON 290-4 is ideal to use for fixed installations or for (small) stages, but also for: Exhibition booths, geometric body for billboards and decorative constructions. HOFKON 290-4 delivers easy handling and high performance. Ideal for: small stage roofs booth construction
order code	11129041000
Product Name	Truss HOFKON 290-4 100cm
MSRP EUR	126.48 EUR
Statisch
max UDL 5m span	1940.40 kg
max UDL 10m span	932.80 kg
max UDL 12m span	759.10 kg
max UDL 15m span	580.40 kg
max CPL 5m span	970.20 kg
max CPL 10m span	466.40 kg
max CPL 12m span	379.50 kg
max CPL 15m span	290.20 kg
deflection at max UDL 5m span	25.40 mm
deflection at max UDL 10m span	102.40 mm
deflection at max UDL 12m span	148.10 mm
deflection at max UDL 15m span	233.60 mm
deflection at max CPL 5m span	20.40 mm
deflection at max CPL 10m span	83.10 mm
deflection at max CPL 12m span	121.10 mm
deflection at max CPL 15m span	193.30 mm
