Produktdetails: Truss HOFKON 220-2 25cm -

Hersteller

Brookstrasse 8
49497 Mettingen

2-point truss, incl. Conical connectors

Info
short summary	2-point truss, incl. Conical connectors
product description	TECHNICAL DATA: Measure: 220 x 35mm Length: 250mm Tube: 35 x 2mm Bracing: 10 x 2mm Material: EN-AW 6060 T66 EUROCODE 9 tested TÜV tested factory incl. conical connector set (2x conical connector, 4x trusspin, 4x r-clip) Measure: 220 x 35 x 250mm Weight: 0,5 kg Powder coating by request Lightness and flexibility are the main characteristics of HOFKON 220-2 series. Its conical connection secures a fast and safe assembly. For fixed installations or for other small applications HOFKON 220-2 is ideal to use such as: Exhibition booths, geometric body for billboards and small decorative constructions. HOFKON 220-2 delivers easy handling and high performance. Ideal for: Booth construction Decoration constructions Store adjustment
order code	11722020250
Product Name	Truss HOFKON 220-2 25cm
MSRP EUR	32.73 EUR
Mechanisch
weight	0.50 kg
width	220.00 mm
height	250.00 mm
length	35.00 mm
Statisch
max UDL 5m span	242.10 kg
max UDL 10m span	111.10 kg
max UDL 12m span	87.70 kg
max UDL 15m span	63.00 kg
max CPL 5m span	121.10 kg
max CPL 10m span	55.50 kg
max CPL 12m span	43.90 kg
max CPL 15m span	31.50 kg
deflection at max UDL 5m span	6.40 mm
deflection at max UDL 10m span	26.20 mm
deflection at max UDL 12m span	38.10 mm
deflection at max UDL 15m span	60.70 mm
deflection at max CPL 5m span	5.20 mm
deflection at max CPL 10m span	21.60 mm
deflection at max CPL 12m span	31.80 mm
deflection at max CPL 15m span	51.70 mm
