Produktdetails: Truss HOFKON 220-3 50cm -

Hersteller

Brookstrasse 8
49497 Mettingen

3-point truss, incl. Conical connectors

Info
short summary	3-point truss, incl. Conical connectors
product description	TECHNICAL DATA: Measure: 220 x 195 mm Length: 500 mm Tube: 35 x 2 mm Bracing: 10 x 2 mm Material: EN AW 6060 T66 EUROCODE 9 tested TÃV tested factory incl. conical connector set (3x conical connector, 6x trusspin, 6x r-clip) Measure: 220 x 195 x 500 mm Weight: 1,2 kg Powder coating by request Lightness and flexibility are the main characteristics of HOFKON 220-3 series. Its conical connection secures a fast and safe assembly. HOFKON 220-3 is ideal to use for fixed installations or for a small exhibition booth, but also for: geometric body for billboards and small decorative constructions. HOFKON 220-3 delivers easy handling and high performance. Ideal for: small exhibition booth decoration constructions store adjustment booth construction
order code	11722030500
Product Name	Truss HOFKON 220-3 50cm
MSRP EUR	51.50 EUR
Mechanisch
weight	1.20 kg
width	220.00 mm
height	500.00 mm
length	195.00 mm
Statisch
max UDL 5m span	176.10 kg
max UDL 10m span	75.00 kg
max UDL 12m span	56.10 kg
max UDL 15m span	35.40 kg
max CPL 5m span	88.10 kg
max CPL 10m span	37.50 kg
max CPL 12m span	28.00 kg
max CPL 15m span	17.70 kg
deflection at max UDL 5m span	11.70 mm
deflection at max UDL 10m span	48.50 mm
deflection at max UDL 12m span	71.10 mm
deflection at max UDL 15m span	114.70 mm
deflection at max CPL 5m span	9.50 mm
deflection at max CPL 10m span	40.90 mm
deflection at max CPL 12m span	61.30 mm
deflection at max CPL 15m span	102.70 mm
