F80-Q7

Barco

1

Technische Daten, Datenblätter, Beschreibungen und Ausschreibungstexte für F80-Q7

Info
product description
Stunning images with superb color performance
Ultimate installation flexibility, 24/7 operation
3D capable|The stunning image quality and laser phosphor light source of Barco's F80 projectors enable you to provide exceptional experiences while saving both time and money. They're designed for fixed installation in a wide range of applications such as museums, board rooms, and auditoriums. Thanks to their 3D capability, they're also perfectly fit for theme park dark rides and interactive experiences.
Superior image quality
The F80-Q7 delivers stunning images with highly saturated colors that allow for accurate color reproduction at all times. What's more it features the powerful Barco Pulse processing that allows for sharper images and less latency thanks to its Single Step Processing (SSP).
Unprecedented business value
With this projector you can increase your uptime while driving costs down. Through its laser-phosphor light source and advanced cooling design, it provides a long operating time without need for lamp changes - resulting in considerable cost-savings on maintenance and consumables.
Ultimate installation flexibility
The F80-Q7 gives you more flexibility in projector location and orientation as it can run in any orientation. Thanks to its wide array of all-glass lenses and wide lens shift ranges, the F80-Q7 accommodates almost any projector configuration.
order code
R9005945
product link
Standard Warranty
3 years
Anschlüsse
Number of DisplayPort inputs
Number of DVI inputs
Number of HDMI inputs
Number of SDI inputs
Steuerung
Integrated Ethernet | RJ 45
yes
Elektrische Eigenschaften
power consumption watt, max
0.00 W
AC Volts, min
100 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
operating temp, min
10.00 °C
operating temp, max
40.00 °C
Operating humidity, min
20 %
Operating humidity, max
80 %
BTU/h
2400.00 BTU/h
Mechanisch
weight
25.50 kg
width
480.00 mm
height
227.00 mm
length
680.00 mm
Aspect Ratio
16:10
Video
Brightness
7000.00 ANSI-lm
Horizontal resolution
2560 px
Vertical resolution
1600 px
Remote interface > RJ 45 / serial 232
yes
