tender specification text |
The system is to consist of a passively separated 2-way loudspeaker, which is driven and protected by a special controller output stage. The loudspeaker shall contain a 15" loudspeaker in a bassreflex tuned cabinet for the low frequency range. The used loudspeakers should be impregnated weatherproof. In the high frequency range, a pressure chamber driver with 1.75 inch ring diaphragm is to operate. The pressure chamber driver used should be coupled to an asymmetrical horn. Its radiation characteristics should be 90° horizontal and 60° vertical and rotatable in 90° steps. The continuous load capacity of the system shall be 600 watts RMS. The loudspeaker should have a nominal impedance of 8 Ohm. The usable system bandwidth should be 50 Hertz to 21,000 Hertz (-3 dB). The maximum peak sound pressure level should be 132 dB, measured with pink noise at a distance of 1 m, under half-space conditions and with a crest factor of 6. The loudspeaker cabinet should be made of birch multiplex and sealed with a weather- and moisture-resistant polyurea coating (PU). The trapezoidal housing should have 35° and 55° inclinations, which make the use as a stage monitor more flexible. The front of the loudspeaker should be equipped with a ball-proof protective grille, which is backed with acoustically neutral foam. Its physical dimensions should be 420 mm in width, 700 mm in height and 380 mm in depth. The loudspeaker shall weigh 17.5 kg. The loudspeaker should have M6 and M8 mounting points with which special accessories can be mounted. The speaker should have an integrated stand flange. With optional flying brackets, the speaker can be mounted horizontally and vertically. The system should be available in left and right speaker versions. The loudspeaker should be connected via two 4-pole SpeakON sockets. The manufacturer's warranty shall be 5 years.
GAEB
TEXT
|
product type |
compact 2-way passive point-source
|
order code |
Coda-G515-PRO-L Coda-G515-PRO-R Coda-G515-PRO-L-W Coda-G515-PRO-R-W Coda-G515-PRO-L-RAL Coda-G515-PRO-R-RAL |
short summary |
G515-PRO is a professional full-range 2-way multifunctional loudspeaker system for touring and installation applications. It has a transmission range of 50Hz - 22kHz (-6dB), an AES power of 600 W and can reach a peak level of 132 dB (6dB Crest). The radiation characteristic is 60° in the vertical and 90° in the horizontal. The horn can be rotated in 90° steps. The system is operated, controlled and monitored by an external CODA AUDIO LINUS system amplifier.
|
product link | |
Product Name |
G515-PRO
|
Audio | |
Frequency response, from |
50 Hz
|
Frequency response, to |
21000 Hz
|
SPL, max |
132.00 dB
|
Nominal power - RMS |
600 W
|
Nominal power - Peak |
2400.00 W
|
impedance |
8 ohm
|
Nominal dispersion angle, horizontal |
90.00 °
|
Nominal dispersion angle, vertical |
60.00 °
|
Connectors | |
Speakon NL4xx |
2 pcs
|
Electrical | |
IP rating |
55
|
Mechanical | |
weight |
17.50 kg
|
width |
420.00 mm
|
height |
700.00 mm
|
length |
370.00 mm
|
enclosure material |
Birch plywood
|
stand adapter |
yes
|
rigging adapter |
no
|
color |
black
|
ceiling installation |
yes
|
wall installation |
yes
|
surface finish |
polyurea coating (PU)
|
special paint |
yes
|
Collect interesting products in a list and download tender specifications at once
Downloads |
---|
CAD-Drawings |
---|
CodaAudio_G515-PRO_CAD-Drawings.zip |
Accessories CAD-Drawings |
CodaAudio_G512-PRO_CAD-Drawings_Accessories.zip |
Acoustical Simulation |
CodaAudio_G-Series_GLL-Files_v1_1.zip |
