FUTURELIGHT Profile 200, 15-28°

FUTURELIGHT

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for FUTURELIGHT Profile 200, 15-28°

Info
order code
51840920
product link
EAN
4026397625721
Product Name
FUTURELIGHT Profile 200, 15-28°
technical overview
Power supply: 100-240 V, 50/60 Hz
Number of DMX channels: 1/2
DMX-512 connection: 3-pin & 5-pin XLR
LED type: 200 W WW COB
Number of LEDs: 1
Beam angle: 15-28°
Gobo outside/image diameter: 85 mm/60 mm
Dimensions: 745 x 276 x 277 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
Weight: 11 kg
IP classification: IP20
Power consumption: 230 W
Lamp type: LED lamp
Beam angle: 15 - 28°
Height: 27,7 cm
Width: 27,6 cm
Length: 74,5 cm
Power connection: Mains Input Socket (M) P-Con (Power-In) Power supply cord with safety plug (M)
LED: 1 x COB (chip-on-board) 200 W WW (homogenous color mix)
Power supply: 110-240 V AC, 50/60 Hz
main features
PRO profile spotlight, warm white 200 W LED, zoom, CRI >90, extremely quiet
-Operable in stand-alone mode or via DMX
-1 or 2 DMX channels selectable
-1 high-power warm white 200 W COB LED
-CRI of >90
-Color temperature: 3300 K
-Functions: dimmer, strobe effect, Master/Slave
-Dimmer speed (step response) adjustable
-Addressing and setting via Control Board with LCD and four operating buttons
-Glass front lens
-Locking possibility at the bracket
-Ideal for theatres and stages
-Focus manually adjustable
-Manually adjustable zoom
-Color filter frame, gobo frame and 4 shutter blades included in delivery
-Suitable for gobos with an outside/image diameter of 85 mm/60 mm
-P-Con power input and feed-through output to power up to 8 devices
-Switch-mode power supply for operation between 100 and 240 volts
-Case color: Black
-Color rendering index (CRI) more than: 90 Ra
-Projection: flicker-free
-Power connection: Mains Input Socket (M) P-Con (Power-In) Power supply cord with safety plug (M) (provided)
-Power out: 1 x P-Con (Power out) gray, mounting version
-Control: Stand-alone; DMX
-LED: 1 x COB (chip-on-board) 200 W WW (homogenous color mix)
Connectors
DMX connector types
both 3/5pin
Control
control channels, min
1 ch
control channels, max
2 ch
Electrical
power consumption watt, max
200.00 W
AC Volts, min
110 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
IP rating
20
power input connector
Powercon
Mechanical
weight
11.00 kg
width
276.00 mm
height
277.00 mm
length
50.00 mm
Optical
beam angle/zoom, min
28.00 °
beam angle/zoom, max
15.00 °
light source
LED
Number of light sources
1 pcs
wattage per light source
200.00 W
WARM WHITE LED source
yes
