Info | |
---|---|
order code |
51841359
|
product link | |
EAN |
4026397561098
|
Product Name |
FUTURELIGHT Stage Pixel Bar 10
|
technical overview |
Power supply: 100-240 V AC, 50/60 Hz Protocol: Art-Net 3 Signal port: 2 x RJ45 (EtherCon) DMX channels: 4/6/8/40/44 DMX connection: 5-pin and 3-pin XLR Flash-rate: 18 Hz Sound-control: via built-in microphone LED number: 10 LED type: 15 W, 4in1 (RGBW) Beam angle: 4° Dimensions (L x W x H): 880 x 159 x 178 mm Ecodesign regulation: Yes Special product: Not designed for household room illumination Purpose: Show effect lighting IP classification: IP20 Lamp type: LED lamp Weight: 9,5 kg Power consumption: 170 W Beam angle: 4° Height: 17,8 cm Depth: 15,9 cm Length: 88 cm Power connection: Mains Input Socket (M) Powercon (Power-In) blue Power supply cord with safety plug (M) DMX channels: 4; 6; 8; 40; 44 LED: 10 x high-power 15 W 4in1 QCL RGBW (homogenous color mix) Power supply: 110-240 V AC, 50/60 Hz |
main features |
Bar with narrow beam 10 x 15 W RGBW LED and frost plate -Equipped with 10 high-power 4in1 LEDs in the colors red, green, blue and white -Particularly bright illuminating power of the LEDs -Collimator lenses for homogeneous beams with 4° beam angle -Removable frost filter -4, 6, 8, 40 or 44 DMX channels selectable -Supports RDM (Remote Device Management) -Each LED can be controlled individually -Quick and easy control via Art-Net -For use via appropriate lighting control software supporting Art-Net -Programmable color change speed, strobe effect and dimmer -Dimmer speed (step response) adjustable -Strobe effect with 1-18 flashes per second -RGBW color mixing -Static colors -Internal programs -DMX-controlled operation or stand-alone operation with Master/Slave function -Manual, sound, DMX- or ArtNet-controlled operation -Sound-control via built-in microphone; adjustable sensitivity -For large stage backgrounds in public places, main halls and lounges -Hanging as well as standing installation possible -Locking possibility at the mounting bracket -Addressing via control panel with LCD screen and four operating buttons -EtherCon input and output -Switch-mode power supply for operation between 100 and 240 volts -Power connection via Neutrik PowerCon jack and included power cable with safety plug -Feed-through output allows to power up to 8 devices -DMX control via any standard DMX controller -Case color: Black -Effect: Strobe effect -Projection: flicker-free -Power connection: Mains Input Socket (M) Powercon (Power-In) blue Power supply cord with safety plug (M) (provided) -Power out: 1 x Powercon (Power out) gray, mounting version -Control: ArtNet; Stand-alone; DMX -LED: 10 x high-power 15 W 4in1 QCL RGBW (homogenous color mix) |
Connectors | |
DMX connector types |
both 3/5pin
|
RJ45 Ethercon |
2
|
Control | |
control channels, min |
4 ch
|
control channels, max |
44 ch
|
protocol-Artnet |
input
|
Electrical | |
power consumption watt, max |
15.00 W
|
AC Volts, min |
110 V
|
AC Volts, max |
240 V
|
AC Frequency, min |
50 Hz
|
AC Frequency, max |
60 Hz
|
IP rating |
20
|
power input connector |
Powercon
|
Mechanical | |
weight |
9.50 kg
|
width |
159.00 mm
|
height |
178.00 mm
|
length |
880.00 mm
|
Optical | |
beam angle/zoom, min |
4.00 °
|
beam angle/zoom, max |
4.00 °
|
light source |
LED
|
Number of light sources |
10 pcs
|
wattage per light source |
15.00 W
|
COLD WHITE LED source |
yes
|
shutter/strobe frequency, max |
18 Hz
|
multichip LED |
yes
|
RED light source |
yes
|
GREEN light source |
yes
|
BLUE light source |
yes
|
