Info | |
---|---|
order code |
51843160
|
product link | |
EAN |
4026397483697
|
Product Name |
FUTURELIGHT PSU-16 Artnet Controller
|
technical overview |
Power supply: 100-240 V AC, 50/60 Hz Protocol: Art-Net 3 Signal input/output: RJ45, CAT5e Signal output Strips: 4 x RJ45, CAT5e Number of Strips: max. 32 per video processor (PXS-20) max. 16 per video processor (PXS-40) Dimensions (L x W x H): 1260 x 226 x 80 mm Power consumption: 300,00 W IP classification: IP20 Weight: 2,4 kg Height: 8 cm Depth: 22,6 cm Width: 26 cm Power supply: 110-240 V AC, 50/60 Hz |
main features |
Video processor for LED PXS-40 + PXS-20 Artnet Strip -Video processor and power supply unit for LED PXS-40/20 Artnet Strip -For use with MADRIX or any other lighting control software supporting Art-Net -Connections for 16 LED PXS-40 Artnet Strips -2 x 16-digit LCD screen for menu settings -Integrated web interface for comfortable configuration and firmware updates through a browser -Useful software tool scans the network and identifies fixtures -RDM-ready -Neutrik PowerCon input and output -Signal distribution via UTP cable -Switch-mode power supply for operation between 100 and 240 volts -Case color: Black -Control: ArtNet |
Control | |
protocol-Artnet |
input
|
Electrical | |
power consumption watt, max |
300.00 W
|
AC Volts, min |
110 V
|
AC Volts, max |
240 V
|
AC Frequency, min |
50 Hz
|
AC Frequency, max |
60 Hz
|
IP rating |
20
|
Mechanical | |
weight |
2.40 kg
|
width |
260.00 mm
|
height |
80.00 mm
|
length |
1260.00 mm
|
Collect interesting products in a list and download tender specifications at once
Downloads |
---|
no files provided by the manufacturer |
