PSSO K-212CM 2-Way Coaxial Wedge 400W

PSSO

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for PSSO K-212CM 2-Way Coaxial Wedge 400W

Info
order code
11041117
product link
EAN
4026397516333
Product Name
PSSO K-212CM 2-Way Coaxial Wedge 400W
technical overview
Components: 30 cm woofer (12"), 3.6 cm horn (1.4")
Connection: 2 x Speakon
Sensitivity: 98 dB
Maximum SPL: 130 dB
Impedance: 8 ohms
Crossover frequency: 1.5 kHz
Dispersion angle: 70° x 70°
Dimensions (H x W x D): 297 x 504 x 437 mm
Weight: 20 kg
Size of woofer: (12") ca. 30 cm
Rated power: 400 W RMS
Program power: 800 W
Frequency range: 64 - 19000 Hz
Height: 29,7 cm
Depth: 43,7 cm
Width: 50,4 cm
Impedance: 8 Ohm
main features
Pro PA speaker, 12" woofer, 1.4" horn, 400 W RMS / 8 ohms
-Rugged 2-way coaxial wedge, qualified for touring applications
-Housing made of 15 mm birch plywood
-30 cm (12") bass speaker with diecast aluminum basket
-36 mm horn tweeter (2.8", 72 mm voice coil)
-Premium custom-made drivers by European manufacturer CELTO Acoustique
-Permium passive 2-way crossover
-Bassreflex system
-Parallel Neutrik Speakon connectors
-Scratch-resistant lacquer surface
-Impact-resistant steel grille with acoustic foam
-Flange for stand installation
-Applications: standing, on a subwoofer or speaker stand, suspended, and as sidefill
Audio
Frequency response, from
64 Hz
Frequency response, to
19000 Hz
impedance
8 ohm
Electrical
power consumption watt, max
400.00 W
Mechanical
weight
20.00 kg
width
504.00 mm
height
297.00 mm
length
437.00 mm

add to list

Collect interesting products in a list and download tender specifications at once

show list

Downloads
Bedienungsanleitung
00083314.pdf
