Info | |
---|---|
order code |
10006817
|
product link | |
EAN |
4026397313444
|
Product Name |
OMNITRONIC PM-404 DJ Mixer
|
technical overview |
Power supply: 230 V AC, 50 Hz, via supplied power unit Inputs: DJ microphone: 6.3 mm jack Minimum input voltage: 1.5 mV RMS/ 1 kohms LINE 1-2: stereo RCA Minimum input voltage: 150 mV RMS/ 270 kohms PHONO 1-2: stereo RCA Minimum input voltage: 3 mV RMS/ 470 kohms Outputs: MASTER: stereo RCA Max. output level: +22 dBu Output voltage: 9 V RMS REC: stereo RCA Output voltage: 225 mV RMS/ 5 kohms Headphones output: 6.3 mm stereo jack/ 16 ohms Tone control: 2 x High: -26 dB to +12 dB/ 12 kHz 2 x Middle: ±15 dB/ 2.5 kHz 2 x Low: -26 dB to +12 dB/ 80 Hz S/N ratio: >80 dB Distortion: Dimensions (WxHxD): 262 x 255 x 84 mm Weight: 2,8 kg Power consumption: 5,00 W Frequency range: 20 - 20000 Hz Height: 8,4 cm Power supply: 230 V AC, 50 Hz Depth: 26,2 cm Width: 25,5 cm Power connection: Mains Input Socket (M) Coaxial power connector (M) Power supply cord with AC adapter (m) |
main features |
Professional 2-channel DJ mixer -2 input channels with gain control and 3-way equalizer with kill function -Level control, 2-way equalizer and talkover button for the DJ microphone channel -Pre-fader listening (CUE) to the stereo input channels via adjustable headphone output, with cue mix control -Replaceable crossfader for crossfading between input channels A and B -High-quality and super-smooth channel faders -10-digit stereo LED level meter and master level control -Inputs: 2 x line/phono (stereo RCA), switchable; DJ microphone and headphones (both 6.3 mm jack) -Outputs: master and record (both stereo RCA) -Operation via supplied power unit -Power connection: Mains Input Socket (M) Coaxial power connector (M) Power supply cord with AC adapter (m) (provided) |
Audio | |
Frequency response, from |
20 Hz
|
Frequency response, to |
20000 Hz
|
Maximum Output Level |
22.00 dBu
|
Signal to Noise Ratio |
80.00 dB
|
Connectors | |
Audio output > RCA / Cinch Stereo-Set (L/R) |
yes
|
Electrical | |
power consumption watt, max |
5.00 W
|
AC Volts, min |
230 V
|
AC Volts, max |
230 V
|
AC Frequency, min |
50 Hz
|
AC Frequency, max |
50 Hz
|
external PSU |
yes
|
Mechanical | |
weight |
2.80 kg
|
width |
262.00 mm
|
height |
255.00 mm
|
length |
262.00 mm
|
Collect interesting products in a list and download tender specifications at once
Downloads |
---|
no files provided by the manufacturer |
