Info | |
---|---|
order code |
10355925
|
product link | |
EAN |
4026397566017
|
Product Name |
OMNITRONIC RRM-502 5-channel rotary mixer
|
technical overview |
Power supply: 230 V AC, 50 Hz Gain: Line: 20 dB Phono: 75 dB Mic: 44 dB Max. output level: 22 dBu Frequency range: Line: 20-20000 Hz Phono: 40-18000 Hz Mic: 20-20000 Hz S/R ratio: Line: 89 dB Phono: 78 dB Mic: 80.5 dB THD: Line: Phono: Tone control: ±10 dB Inputs: LINE: RCA L/R PHONO: RCA L/R DJ microphone: XLR INSERT IN: RCA L/R Outputs: MASTER: XLR/RCA L/R BOOTH: XLR/RCA L/R REC: RCA L/R LINK: RCA L/R INSERT OUT: RCA L/R Headphones output: 6.3 mm jack (min. 32 ohms) Dimensions (L x W x H): 200 x 482 x 93 mm Weight: 5 kg Power consumption: 15 W Height: 8,9 cm Depth: 20 cm Width: 48,3 cm Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) Power supply: 230 V AC, 50 Hz |
main features |
5-channel rotary mixer for DJs -Classic rotary mixer with 5 input channels for DJs -Vintage ALPS potentiometers (Blue Velvet RK27) -High-grade components ensure long life and excellent sound quality -Gain control, cue button and source selector per channel -10 line inputs, 3 of which switchable phono/line -DJ microphone channel with separate level control and 2-band EQ -Prefader listening to input channels and the master output via adjustable headphones output, with cue mix/split function -Master, booth and balance control -Record output, switchable pre/post -FX send/return for external FX unit -Rack installation, 2 U -Housing design: (19") 48,3 cm rack installation -Height unit: 2 U -Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) (provided) |
Audio | |
Maximum Output Level |
22.00 dBu
|
Connectors | |
Audio output > RCA / Cinch Stereo-Set (L/R) |
yes
|
Audio output > XLR 3P |
yes
|
Electrical | |
power consumption watt, max |
15.00 W
|
AC Volts, min |
230 V
|
AC Volts, max |
230 V
|
AC Frequency, min |
50 Hz
|
AC Frequency, max |
50 Hz
|
power input connector |
IEC-60320 C13/C14
|
Mechanical | |
weight |
5.00 kg
|
width |
483.00 mm
|
height |
89.00 mm
|
length |
200.00 mm
|
