Info | |
---|---|
order code |
10453007
|
Product Name |
OMNITRONIC LUB-27 Speaker Switch Box
|
product link | |
EAN |
4026397383096
|
technical overview |
Power supply: 100-240 V AC, 50/60 Hz via supplied power unit 12 V/1.5 A Rated power: 25 A per channel Connectors: pairs of screw terminals Remote control: 2 x 1.5 V micro batteries (type AAA) Coverage: 10 m Extension connection: 3.5 mm jack Dimensions (L x W x H): 482 x 220 x 78 mm (19", 2 U) Weight: 3,2 kg Power consumption: 30,00 W Height: 8,9 cm Width: 48,3 cm Power connection: Mains Input Socket (M) Coaxial power connector (M) Power supply cord with Euro plug (M) Depth: 22 cm Power supply: 110-240 V AC, 50/60 Hz |
main features |
Speaker/amplifier switch box with IR remote control -7-channel switch box for speaker pairs or amplifiers -Ideal for showrooms for comparing the performance of different speakers or amplifiers -Operating mode 1: switching over on 7 speaker pairs to 2 stereo amplifiers with A/B selection -Operating mode 2: switching over on 7 stereo amplifiers to 2 speaker pairs with A/B selection -Multi-zone function also allows for freely combining the 7 speaker pairs in operating mode 1 -Parallel connection of 2 units for extension to 14 zones possible in operating mode 1, connection cables optional -High-power audio signal transmission, power rating: 25 A per channel -LED indicators for each status -Mute function -Automatic recall of last-used settings after switching on -Incl. IR remote control -Optional extension IR receiver -Connections via pairs of screw terminals -Black metal housing with aluminum front panel -Operation via supplied switch mode power unit -Rack installation, 2 U -Height unit: 2 U -Housing design: (19") 48,3 cm rack installation -Power connection: Mains Input Socket (M) Coaxial power connector (M) Power supply cord with Euro plug (M) (provided) -Control: IR remote control (provided) |
Electrical | |
power consumption watt, max |
30.00 W
|
AC Volts, min |
110 V
|
AC Volts, max |
240 V
|
power input connector |
Europlug
|
AC Frequency, min |
50 Hz
|
AC Frequency, max |
60 Hz
|
Mechanical | |
weight |
3.20 kg
|
width |
483.00 mm
|
height |
89.00 mm
|
length |
220.00 mm
|
