OMNITRONIC BOB-10A Subwoofer active white

OMNITRONIC

1
2
3
4

Technical specifications, datasheets, descriptions and tender texts for OMNITRONIC BOB-10A Subwoofer active white

Info
order code
11038871
product link
EAN
4026397650174
Product Name
OMNITRONIC BOB-10A Subwoofer active white
technical overview
Power supply: 115/230 V AC, 50/60 Hz
Power consumption: 1060 W
Amplifier power: LF 300 W RMS + HF 2 x 300 W RMS
LF speaker: 25 cm (10") with 50 mm voice coil
Frequency range: 45-250 Hz
Sensitivity: 100 dB
Maximum SPL: 125 dB
Signal input: combination XLR/6.3 mm jack L/R and RCA L/R
Parallel output: XLR L/R
Satellite: Speaker L/R
Dimensions (L x W x H): 470 x 300 x 430 mm
Weight: 16.5 kg
Weight: 17,00 kg
Size of woofer: (10") ca. 25 cm
Frequency range: 45 - 250 Hz
Number of bass-woofer: 1 Pc/Pcs
Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M)
Color: White
Bass
Width: 30 cm
Height: 43 cm
Depth: 47 cm
Material: MDF (Medium-density fibreboard)
main features
10" subwoofer with DSP and Bluetooth for the BOB series
-10" bassreflex subwoofer with DSP and 900 watts RMS power
-Flexibly extendable with BOB-4 satellites for 2.1, 4.1 and 8.1 configurations
-DSP-controlled class D amplifier (300 W + 2 x 300 W)
-Integrated Bluetooth audio streaming
-4 EQ presets with indicators
-Signal limiter and crossover
-Signal inputs via combo jacks (XLR/6.3 mm jack) and RCA
-Parallel XLR outputs for linking further BOB systems or active systems
-Separate volume controls for subwoofer and satellites L/R
-Stereo/mono selection
-Phase reversal switch
-Fault, limit, signal and power indicators
-Built-in protection circuits: soft start, short-circuit, limiter, overcurrent, overheat
-Two M20 metal flanges for mounting satellite speakers
-MDF enclosure with scratch-resistant lacquer surface and steel grille
-Built-in handles and low weight for ease of transport
-Stackable via recesses when set up horizontally
-Delivery includes two speaker cables
-For mobile live and DJ applications and installation in bars, stores, conference rooms and home theaters
-Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) (provided)
-DSP: Digital signal processor
-Control: Bluetooth
Audio
Frequency response, from
45 Hz
Frequency response, to
250 Hz
Electrical
power consumption watt, max
1060.00 W
power input connector
IEC-60320 C13/C14
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
Mechanical
weight
17.00 kg
width
300.00 mm
height
430.00 mm
length
470.00 mm
enclosure material
MDF (Medium-density fibreboard)

add to list

Collect interesting products in a list and download tender specifications at once

show list

Downloads
Bedienungsanleitung
00119653.pdf
