OMNITRONIC PAS-151A PRO DSP Active Subwoofer

OMNITRONIC

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for OMNITRONIC PAS-151A PRO DSP Active Subwoofer

Info
order code
11039630
product link
EAN
4026397527452
Product Name
OMNITRONIC PAS-151A PRO DSP Active Subwoofer
technical overview
Power supply: 230 V AC, 50 Hz
Woofer: 38 cm (15")
Signal input: XLR L/R
Signal output: XLR L/R
Sensitivity: 96 dB
Maximum SPL: 126 dB
Crossover frequency: 80-200 Hz
Acoustic loading: Bassreflex
Amplifier: Class D
Dimensions (W x D x H): 680 x 460 x 590 mm
Weight: 43 kg
Program power: 1000 W
Rated power: 500 W RMS
Power consumption: 670 W
Size of woofer: (15") ca. 38 cm
Number of bass-woofer: 1 Pc/Pcs
Frequency range: 45 - 120 Hz
Height: 59 cm
Depth: 68 cm
Width: 46 cm
Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M)
Power supply: 230 V AC, 50 Hz
main features
Active 15" PA bassreflex subwoofer, 500 W
-Active high-power bassreflex subwoofer for permanent installations and touring purposes
-Housing made of 18 mm plywood multilayered glued
-1000 W Class D power amplifier with switch mode power supply
-38 cm (15") bass speaker
-Balanced signal input XLR/6.3 mm jack L/R
-Parallel XLR line output L/R
-Adjustable crossover frequency 80-200 Hz
-DSP-controlled limiter
-Phase reversal switch
-M20 metal flange for mounting top speakers
-Incorporated carrying handles
-Scratch-resistant lacquer surface, steel grille and rubber feet
-Matching castors optionally available
-Transport aid: Wheels optional
-DSP: Digital signal processor
-Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) (provided)
Audio
Frequency response, from
45 Hz
Frequency response, to
120 Hz
Electrical
power consumption watt, max
670.00 W
AC Volts, min
230 V
AC Volts, max
230 V
power input connector
IEC-60320 C13/C14
AC Frequency, min
50 Hz
AC Frequency, max
50 Hz
Mechanical
weight
43.00 kg
width
460.00 mm
height
590.00 mm
length
680.00 mm

add to list

Collect interesting products in a list and download tender specifications at once

show list

Downloads
Bedienungsanleitung
00085351.pdf
