OMNITRONIC LI-206B MK2 2-Way Top

OMNITRONIC

1
2
3
4

Technical specifications, datasheets, descriptions and tender texts for OMNITRONIC LI-206B MK2 2-Way Top

Info
order code
11038983
product link
EAN
4026397493931
Product Name
OMNITRONIC LI-206B MK2 2-Way Top
technical overview
Components: 16.5 cm woofer (6.5"), 2.5 cm calotte (1")
Connection: 2-pole plug-in screw terminal
Sensitivity: 89 dB
Maximum SPL: 109 dB
Crossover frequency: 2200 kHz
Dispersion angle: 120°
Dimensions (H x W x D): 320 x 200 x 200 mm
Weight: 4,7 kg
Program power: 100 W
Rated power: 50 W RMS
Color: Black
Size of woofer: (6,5") ca. 17 cm
Frequency range: 80 - 20000 Hz
Height: 32 cm
Depth: 20 cm
Width: 20 cm
Attachment: Panning and tilting mounting bracket for ceiling or wall installation in most varying angles
main features
Speaker with mount,, 6.5" full-range speaker and 1" horn tweeter, 50 W RMS
-Dedicated full-range bassreflex system for fixed installation
-16.5 cm (6.5") bass speaker and 25 mm (1") horn tweeter, with PTC tweeter protection
-Attractive trapezoidal cabinet made of 8/12 mm plywood
-Scratch-resistant lacquer surface in black or white
-Supplied with movable mounting bracket for ceiling or wall installation
-Impact-resistant steel grille with acoustic foam
-2 x M10 thread inserts
-For PA applications in restaurants, bars, discos and shops
Audio
Frequency response, from
80 Hz
Frequency response, to
20000 Hz
Electrical
power consumption watt, max
50.00 W
Mechanical
weight
4.70 kg
width
200.00 mm
height
320.00 mm
length
200.00 mm

add to list

Collect interesting products in a list and download tender specifications at once

show list

Downloads
Bedienungsanleitung
00076709.pdf
