OMNITRONIC GCS-510 Ceiling Speaker 10W/pa

OMNITRONIC

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for OMNITRONIC GCS-510 Ceiling Speaker 10W/pa

Info
order code
80710114
product link
EAN
4026397349139
Product Name
OMNITRONIC GCS-510 Ceiling Speaker 10W/pa
technical overview
Input: 100 V or 8 ohms
Components: 13 cm woofer (5"), 4 cm tweeter (1,5")
Sensitivity: 86 dB
Maximum SPL: 102 dB
Dimensions (L x W x H): 360 x 345 x 150 mm
Size of woofer: (5") ca. 13 cm
Rated power: 10 W RMS
Program power: 20 W
Frequency range: 75 - 18000 Hz
Height: 15 cm
Depth: 34,5 cm
Width: 36 cm
Weight: 7,25 kg
Impedance: 100 V ELA
main features
Hi-fi ceiling mount speaker with firedome
-2-way system with 13 cm woofer (5") and 1.5" tweeter
-For 8-ohm and 100 V systems
-Front-mounted 4-step power selector
-Steel firedome for safety in case of fire
-Sturdy steel grille in off-white
-Installation via drill holes in the housing
-Incl. mounting bracket for secure installation
Audio
Frequency response, from
75 Hz
Frequency response, to
18000 Hz
impedance
8 ohm
Electrical
power consumption watt, max
10.00 W
Mechanical
weight
7.25 kg
width
345.00 mm
height
150.00 mm
length
345.00 mm

add to list

Collect interesting products in a list and download tender specifications at once

show list

Downloads
Bedienungsanleitung
00043183.pdf
