OMNITRONIC CSP-6 Ceiling Speaker
OMNITRONIC
Technical specifications, datasheets, descriptions and tender texts for OMNITRONIC CSP-6 Ceiling Speaker
| Info | |
|---|---|
| order code |
80710250
|
| product link | |
| EAN |
4026397414493
|
| Product Name |
OMNITRONIC CSP-6 Ceiling Speaker
|
| technical overview |
Input voltage: 100 V Components: 15 cm speaker (6") 6 W RMS (red) COM (black) Sensitivity: 91 dB, ±3 dB Maximum SPL: 97 dB Dimensions (D x D): 188 x 70 mm Mounting cutout: 164 mm ø Weight: 0,5 kg Size of woofer: (6") ca. 15 cm Rated power: 6 W RMS Program power: 12 W Frequency range: 100 - 17000 Hz Diameter: 18,8 cm Depth: 7 cm Impedance: 100 V ELA |
| main features |
6" flush-mount speaker, 100 V, 6 W RMS, Ø 164 mm -15 cm full-range speaker (6") -100 V transformer with 2 power taps -Easy mounting via spring clamps, similar to standard flush-mount lights -White high-impact polystyrene (HIPS) enclosure and grille -For speech and background music in indoor PA systems |
| Audio | |
| Frequency response, from |
100 Hz
|
| Frequency response, to |
17000 Hz
|
| Electrical | |
| power consumption watt, max |
6.00 W
|
| Mechanical | |
| weight |
0.50 kg
|
| length |
70.00 mm
|
| outer diameter |
188 mm
|
