| Info | |
|---|---|
| order code |
80710404
|
| product link | |
| EAN |
4026397279603
|
| Product Name |
OMNITRONIC WP-10W Ceiling Speaker
|
| technical overview |
Input voltage: 100 V Components: 13 cm speaker (5") 5 W RMS (yellow) 10 W RMS (red) COM (blue) Sensitivity: 91 dB, ±3 dB Maximum SPL: 100 dB Weight: 1,5 kg IP classification: IP44 Size of woofer: (5") ca. 13 cm Rated power: 10 W RMS Program power: 20 W Frequency range: 130 - 15000 Hz Height: 13,8 cm Depth: 20,5 cm Impedance: 100 V ELA Diameter: 13,8 cm |
| main features |
Ceiling speaker white ABS, 10 watts -100 V speaker system with 3 power taps -Weather-proof design (IP44) in scratch-resistant plastic housing (ABS) with metal grille -2 m connection cable with integrated steel wire for the installation -Ideal for covering large areas from high ceilings -For outdoor and indoor amplifying systems |
| Audio | |
| Frequency response, from |
130 Hz
|
| Frequency response, to |
15000 Hz
|
| Electrical | |
| power consumption watt, max |
10.00 W
|
| IP rating |
44
|
| Mechanical | |
| weight |
1.50 kg
|
| height |
138.00 mm
|
| length |
205.00 mm
|
| outer diameter |
138 mm
|
