| Info | |
|---|---|
| order code |
11038772
|
| product link | |
| EAN |
4026397537215
|
| Product Name |
OMNITRONIC VFM-212A 2-Way Speaker, active
|
| technical overview |
Power supply: 100-240 V AC, 50/60 Hz LF speaker: 30 cm bass/mids (12") with 40 mm voice coil HF speaker: 25 mm compression driver (1") Inputs: 2 Mic: 3-pin XLR or 6.3 mm jack, unbal. 1 Line: stereo RCA Outputs: 1 Line: stereo RCA Maximum SPL: 120 dB Weight: 10,50 kg Program power: 280 W Rated power: 140 W RMS Size of woofer: (12") ca. 30 cm Number of bass-woofer: 1 Pc/Pcs Frequency range: 50 - 20000 Hz Height: 63 cm Depth: 34,2 cm Width: 42 cm Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) Power supply: 110-240 V AC, 50/60 Hz |
| main features |
Aktive speaker, 12" woofer, 1" driver, 140 W RMS -Class A/B circuitry: optimum sound and power at low weight and compact dimensions -2-way bass-reflex system with 30 cm woofer and 2.5 cm tweeter -2 mic inputs with separate level controls -Line input, RCA -Master control with 2-way tone control, clip and power LED -Line output for linking further active speaker systems -2 wheels for easy transport -Stable plastic housing with protective grille and handles -Flange for stand installation -Can be used as floor monitor, standing, on a speaker stand or wall holder -For mobile live and DJ applications -Master equalizer: 1 x 2 band tone control -Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) (provided) |
| Audio | |
| Frequency response, from |
50 Hz
|
| Frequency response, to |
20000 Hz
|
| Electrical | |
| power consumption watt, max |
140.00 W
|
| AC Volts, min |
110 V
|
| AC Volts, max |
240 V
|
| power input connector |
IEC-60320 C13/C14
|
| AC Frequency, min |
50 Hz
|
| AC Frequency, max |
60 Hz
|
| Mechanical | |
| weight |
10.50 kg
|
| width |
420.00 mm
|
| height |
630.00 mm
|
| length |
342.00 mm
|
Collect interesting products in a list and download tender specifications at once
| Downloads |
|---|
| Bedienungsanleitung |
|---|
| 00100027.pdf |
