OMNITRONIC VFM-2212 2-Way Speaker

OMNITRONIC

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for OMNITRONIC VFM-2212 2-Way Speaker

Info
order code
11038777
product link
EAN
4026397596656
Product Name
OMNITRONIC VFM-2212 2-Way Speaker
technical overview
LF speaker: 2 x 30 cm bass/mids (12") with 40 mm voice coil
HF speaker: 25 mm compression driver (1")
Connection: 2 x Speaker
Sensitivity: 96 dB
Maximum SPL: 122 dB
Weight: 12 kg
Size of woofer: (12") ca. 30 cm
Number of bass-woofer: 2 Pc/Pcs
Rated power: 150 W RMS
Program power: 300 W
Frequency range: 50 - 20000 Hz
Height: 95 cm
Depth: 39,5 cm
Width: 32 cm
Impedance: 4 Ohm
main features
Passive speaker, 2 x 12" woofer, 1" driver, 150 W RMS, 8 ohms
-2-way bassreflex system with 2 x 30 cm woofer and 2.5 cm tweeter
-Speaker connections
-Stable plastic housing with protective grille and handles
-Easy handling thanks to low weight
-Flange for stand installation
-Can be used as floor monitor, standing, on a speaker stand or wall holder
-For mobile live and DJ applications
-Transport aid: Trolley
Audio
Frequency response, from
50 Hz
Frequency response, to
20000 Hz
impedance
4 ohm
Electrical
power consumption watt, max
150.00 W
Mechanical
weight
12.00 kg
width
320.00 mm
height
950.00 mm
length
395.00 mm

add to list

Collect interesting products in a list and download tender specifications at once

show list

Downloads
Bedienungsanleitung
00104894.pdf
