OMNITRONIC MIC SHC-2 Gooseneck Microphone
|
technical overview |
Type: Condenser Polar pattern: Cardioid Sensitivity: -40 dB (±3 dB) Output impedance: 600 ohms Power supply: 48 V DC phantom power or 9 V battery Connector: 3-pin XLR Dimensions (L x W x H): Base 142 x 132 x 54 mm Dimensions (L x W): Microphone 520 x 21 mm Weight: 1 kg Phantom power: 48 V DC; Or intern battery 9 V V DC Frequency range: 80 - 15000 Hz |
main features |
Electret gooseneck microphone -Conference microphone with condenser technology -For conference systems, speaker desks or as PA microphone -Optimum speech intelligibility even at greater distances -Operation via external phantom power (48 V DC voltage) or internal 9 V battery (not included) -Gooseneck bends at two positions -Color ring glows during operation -Metal desktop base with on/off switch -Mute function: On/off/mute switch |
Audio | |
Frequency response, from |
80 Hz
|
Frequency response, to |
15000 Hz
|
Output impedance |
600 ohm
|
Electrical | |
DC Volts, min |
48 V
|
DC Volts, max |
48 V
|
Mechanical | |
weight |
1.00 kg
|
width |
132.00 mm
|
height |
54.00 mm
|
length |
142.00 mm
|
