Info | |
---|---|
order code |
20000530
|
Product Name |
OMNITRONIC PA Set AZX passive L
|
product link | |
EAN |
4026397651317
|
technical overview |
11039028 OMNITRONIC AZX-212 2-Way Top 200W Rated power: 200 W RMS Program power: 400 W LF speaker: 30 cm bass/mids (12") with 50 mm voice coil HF speaker: 3,5 cm compression driver (1.35") Connection: 2 x Speaker Sensititvity: 94 dB Frequency range: 55 - 18000 Hz Number of bass-woofer: 1 Pc/Pcs Size of woofer: (12") ca. 30 cm Impedance: 8 Ohm Weight: 17,10 kg Width: 43 cm Depth: 40,5 cm Height: 67 cm Material: MDF (Medium-density fibreboard) 11039040 OMNITRONIC AZX-115 PA Subwoofer 400W Rated power: 400 W RMS Program power: 800 W Connection: 2 Speaker sockets Sensitivity: 94 dB Impedance: 8 ohms Dimensions (H x W x D): 600 x 580 x 520 mm Size of woofer: (15") ca. 38 cm Number of bass-woofer: 1 Pc/Pcs Frequency range: 40 - 250 Hz Weight: 24,10 kg Impedance: 8 Ohm Width: 58 cm Depth: 60 cm Height: 52 cm Material: MDF (Medium-density fibreboard) |
main features |
11039028 OMNITRONIC AZX-212 2-Way Top 200W Passive speaker with 12" woofer, 1.35" driver and 200 W RMS -2-way bass-reflex system with 30 cm woofer and 3.5 cm titan driver -Speaker connections -Stable MDF housing with protective grille and handles -Dual flange with 0° and 5° tilt angle enables flexible positioning -M10 threaded inserts for suspended installation -Applications: standing, as monitor, on a subwoofer or speaker stand, suspended 11039040 OMNITRONIC AZX-115 PA Subwoofer 400W 15" bassreflex subwoofer with 400 W RMS, 8 ohms -38 cm (15") bass speaker with 63 mm voice coil -Parallel Speaker connectors -M20 metal flange for mounting top speakers -Carrying handles -Housing made of 15 mm MDF -Scratch-resistant lacquer surface -Impact-resistant steel grille with acoustic foam |
Audio | |
Frequency response, from |
55 Hz
|
Frequency response, to |
18000 Hz
|
impedance |
8 ohm
|
Electrical | |
power consumption watt, max |
200.00 W
|
Mechanical | |
weight |
17.10 kg
|
width |
430.00 mm
|
height |
670.00 mm
|
length |
405.00 mm
|
enclosure material |
MDF (Medium-density fibreboard)
|
