Ayrton has developed Bora, its new feature- packed 750 W wash luminaire, using a radical approach. Its specific function is to establish the perfect atmosphere for your creative design. Fitted with a frontal 178 mm spherical lens, the proprietary optical system using 13 high-quality lenses was developed specifically for “wash” applications. It features an 8:1 zoom ratio for a wide zoom range from 8° to 64°. The optics produces an extremely uniform flat beam with no hot spot, ensuring a perfectly homogeneous colour mix regardless of the colour combination selected. Bora comes in two versions, each to meet the specific requirements of lighting professionals. Bora-S is designed for scenic applications. It is equipped with a new LED module calibrated at 8000 K, delivering powerful metallic white light with record-breaking output of 42,000 lumens. Devised specifically for applications that require perfect.
GAEB
TEXT
|
| product description |
Ayrton has developed Bora, its new feature- packed 750 W wash luminaire, using a radical approach. Its specific function is to establish the perfect atmosphere for your creative design. Fitted with a frontal 178 mm spherical lens, the proprietary optical system using 13 high-quality lenses was developed specifically for “wash” applications. It features an 8:1 zoom ratio for a wide zoom range from 8° to 64°. The optics produces an extremely uniform flat beam with no hot spot, ensuring a perfectly homogeneous colour mix regardless of the colour combination selected. Bora comes in two versions, each to meet the specific requirements of lighting professionals. Bora-S is designed for scenic applications. It is equipped with a new LED module calibrated at 8000 K, delivering powerful metallic white light with record-breaking output of 42,000 lumens. Devised specifically for applications that require perfect.
|
| product link | |
| Connectors | |
| total number of DMX inputs |
1 pcs
|
| total number of DMX outputs |
1 pcs
|
| DMX connector types |
5pin
|
| built-in Switch |
yes
|
| Control | |
| max Dimmer resolution |
16 bit
|
| control channels, min |
36 ch
|
| control channels, max |
56 ch
|
| RDM |
yes
|
| wireless dmx |
yes
|
| protocol-DMX |
both
|
| protocol-Artnet |
both
|
| Electrical | |
| power consumption watt, max |
1150.00 W
|
| AC Volts, min |
100 V
|
| AC Volts, max |
240 V
|
| AC Frequency, min |
50 Hz
|
| AC Frequency, max |
60 Hz
|
| IP rating |
20
|
| operating temp, min |
-10.00 °C
|
| operating temp, max |
45.00 °C
|
| built-in dimmer |
LED PWM
|
| power input connector |
Truecon
|
| cooling |
active
|
| Mechanical | |
| weight |
37.80 kg
|
| width |
494.00 mm
|
| height |
737.00 mm
|
| length |
280.00 mm
|
| pan range |
540 °
|
| tilt range |
270 °
|
| color |
black
|
| truss mountable |
yes
|
| recessed installation |
yes
|
| Optical | |
| output lumen, max |
42000 lm
|
| beam angle/zoom, min |
8.00 °
|
| beam angle/zoom, max |
64.00 °
|
| light source |
LED
|
| Number of light sources |
1 pcs
|
| wattage per light source |
750.00 W
|
| optics/projection type |
Washlight
|
| number of separate pixel zones |
1
|
| shutter/strobe frequency, max |
25 Hz
|
| variable/linear frost |
yes
|
| iris min |
15 %
|
| iris max |
100 %
|
| color temperature, min |
6500 K
|
| min CRI |
70 CRI
|
| drop-in frosts |
1 pcs
|
| lens diameter |
178 mm
|
| beam shape |
round
|
| fixed/virtual colorwheels |
2 pcs
|
| gobowheels total |
1 pcs
|
| rotating gobowheels |
1 pcs
|
| number of fixed gobos |
6 pcs
|
| number of rotating gobos |
6 pcs
|
| beam shapers/framing/barndoors |
yes
|
| shaper rotation range degrees |
90 °
|
| prism |
no
|
| separate CTO wheel |
yes
|
| CMY colormixing |
dual flag
|
