Info | |
---|---|
order code |
41700011
|
product link | |
EAN |
4026397601374
|
Product Name |
EUROLITE AKKU Flat Light 1 bl
|
technical overview |
Power supply: 12.6 V, 2.5 A via charger (100-240 V, 50/60 Hz) Battery pack type: Li-ion 11.1 V, 5200 mAh (57.72 Wh) Battery operation: depending on program used up to 18 hours Recharging time: 4 hours Battery remote control: CR2032 button cell 3 V DMX channels: 3/4/6/8/10 Sound-control: via built-in microphone Wireless signal transmission: 2.4 GHz (ISM), 126 channels LED type: 15 W RGBW (4in1) LED number: 1 Beam angle: 8° Dimensions (L x W x H): 168 x 138 x 62 mm Ecodesign regulation: Yes Special product: Not designed for household room illumination Purpose: Show effect lighting IP classification: IP20 Lamp type: LED lamp Weight: 1,3 kg Cooling fan: No, cooling by convection Beam angle: 8° Height: 6,2 cm Depth: 13,8 cm Width: 16,8 cm DMX channels: 3; 4; 6; 8; 10 Power connection: Battery/battery pack; Mains Input Socket (M) Coaxial power connector (M) Power supply cord with Euro plug (M) LED: 1 x high-power 15 W 4in1 QCL RGBW (homogenous color mix) |
main features |
Flat spotlight with 15 W RGBW LED, QuickDMX transceiver & bracket -With QuickDMX transceiver - cordless, flexible and versatile -Equipped with a 15 W QCL LED in red, green, blue and white -Compact and bright -Elegant housing for indoor use -With integrated QuickDMX transmitter/receiver for the wireless transmission of DMX512 signals -Operation via built-in rechargeable lithium-ion battery with up to 18 hours operating time -Integrated automatic charging of the battery with indicator -DMX-controlled operation or stand-alone operation with Master/Slave function -Controllable via EUROLITE IR-13 remote control; included in the delivery -3, 4, 6, 8 or 10 DMX channels selectable -Functions: static colors, stepless RGBW color mixture, internal programs, dimmer, strobe effect with variable speed, sound-control -Dimmer speed (step response) adjustable -Addressing and setting via Control Board with touch buttons and LCD -Kensington Security Slot to secure the device against theft -Hanging as well as standing installation possible -Inclination angle manually adjustable via the bracket -Charger included in delivery -Switch-mode power supply for operation between 100 and 240 volts -DMX512 control via any standard DMX controller and suitable wireless transmitter -Case color: Black -Effect: Strobe effect -Projection: flicker-free -Power connection: Battery/battery pack; Mains Input Socket (M) Coaxial power connector (M) Power supply cord with Euro plug (M) (provided) -Control: Master/slave function; IR remote control (provided); QuickDMX; Stand-alone -LED: 1 x high-power 15 W 4in1 QCL RGBW (homogenous color mix) |
Control | |
control channels, min |
3 ch
|
control channels, max |
10 ch
|
Electrical | |
power consumption watt, max |
15.00 W
|
IP rating |
20
|
power input connector |
Europlug
|
cooling |
passive
|
Battery runtime (max) |
18.00 h
|
Battery recharge time (max) |
4.00 h
|
Mechanical | |
weight |
1.30 kg
|
width |
168.00 mm
|
height |
62.00 mm
|
length |
168.00 mm
|
Optical | |
beam angle/zoom, min |
8.00 °
|
beam angle/zoom, max |
8.00 °
|
light source |
LED
|
Number of light sources |
1 pcs
|
wattage per light source |
15.00 W
|
multichip LED |
yes
|
COLD WHITE LED source |
yes
|
RED light source |
yes
|
GREEN light source |
yes
|
BLUE light source |
yes
|
