EUROLITE LED PFE-50 3000K Profile Spot

EUROLITE

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED PFE-50 3000K Profile Spot

Info
order code
40001800
product link
EAN
4026397579284
Product Name
EUROLITE LED PFE-50 3000K Profile Spot
technical overview
Power supply: 100-240 V AC, 50/60 Hz
LED type: COB 50 W
LED number: 1
Color temperature: 3000 K
Dimensions (L x W x H) incl. lens tube (optional): 305 x 134 x 238 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
Beam angle: 19°; 26°; 36°; 50°
Weight: 2 kg
IP classification: IP20
Power consumption: 55 W
Lamp type: LED lamp
Height: 23,8 cm
Length: 30,5 cm
Power connection: Mains Input Socket (M) 3-pin screw plug connector (M) IP Power supply cord with safety plug (M)
Width: 13,4 cm
LED: 1 x COB (chip-on-board) 50 W WW (homogenous color mix)
Power supply: 110-240 V AC, 50/60 Hz
main features
Handy stage spotlight with 50 W COB LED in modular construction system, CRI >80
-Modular construction kit that can be customized to individual preferences
-Locking possibility at the mounting bracket
-4 shutter blades
-Color-filter frame
-Gobo holder for own gobos with an outside diameter between 35 and 60 mm, image diameter max. 27 mm
-Fan-cooled
-Delivery without lens tube (necessary accessory)
-Matching lens tube (beam angle 19°/26°/36°/50°), adjustable iris and DMX interface available as accessories
-Dimmer and strobe, master/slave functions adjustable via optional DMX interface
-Power connection via included power cable with safety plug
-Switch-mode power supply for operation between 100 and 240 volts
-Feed-through output allows to power up to 8 devices
-Color rendering index (CRI) more than: 80 Ra
-Case color: Black
-Projection: flicker-free
-Power connection: Mains Input Socket (M) 3-pin screw plug connector (M) IP Power supply cord with safety plug (M) (provided)
-Power out: 1 x 3-pin screw plug connector (F) IP
-Control: without
-LED: 1 x COB (chip-on-board) 50 W WW (homogenous color mix)
Electrical
power consumption watt, max
50.00 W
AC Volts, min
110 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
IP rating
20
Mechanical
weight
2.00 kg
width
134.00 mm
height
238.00 mm
length
50.00 mm
Optical
light source
LED
light source color temperature
3000 K
color temperature, min
3000 K
color temperature, max
3000 K
Number of light sources
1 pcs
wattage per light source
50.00 W
WARM WHITE LED source
yes

add to list

Collect interesting products in a list and download tender specifications at once

show list

Downloads
Bedienungsanleitung
00099596.pdf
