EUROLITE LED CSL-320 Spotlight 6000K black

EUROLITE

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED CSL-320 Spotlight 6000K black

Info
order code
41600500
product link
EAN
4026397588989
Product Name
EUROLITE LED CSL-320 Spotlight 6000K black
technical overview
Power supply: 100-240 V, 50/60 Hz
DMX channels: 3
DMX connection: 3-pol. XLR
LED type: 10 W
LED number: 32
Color temperature: 6000 K
Beam angle: 7°
Dimensions: 395 x 265 x 380 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
IP classification: IP20
Beam angle: 7°
Weight: 8 kg
Lamp type: LED lamp
Height: 25 cm
Depth: 21 cm
Width: 23,5 cm
Power connection: Mains Input Socket (M) P-Con (Power-In) Power supply cord with safety plug (M)
LED: 32 x high-power 10 W CW (homogenous color mix)
intern
Power consumption: 240 W
main features
Bright, cold white beam light, narrow beam angle and 32 x 10 W LED
-DMX512 control possible via any commercial DMX controller (occupies 3 channels)
-Comfortable addressing and setting via control panel with LED display and four operating buttons
-Functions: dimmer, strobe
-Dimmer speeds (step response) adjustable via DMX
-Equipped with 32 x 10 W LED
-Color temperature 6000 K
-Mounting bracket for installation on a stand or a crossbeam
-Locking possibility at the mounting bracket
-Barndoors included in delivery
-Power connection via P-Con jack and included power cable with safety plug
-Switch-mode power supply for operation between 100 and 240 volts
-Feed-through output allows to power up to 6 devices
-Color temperature: 6000 K
-Case color: Black
-Power connection: Mains Input Socket (M) P-Con (Power-In) Power supply cord with safety plug (M) (provided)
-Power out: 1 x P-Con (Power out) gray, mounting version
-Control: Stand-alone; DMX
-LED: 32 x high-power 10 W CW (homogenous color mix)
Control
control channels, min
3 ch
control channels, max
3 ch
Electrical
power consumption watt, max
10.00 W
AC Volts, min
100 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
IP rating
20
power input connector
Powercon
Mechanical
weight
8.00 kg
width
235.00 mm
height
250.00 mm
length
210.00 mm
Optical
beam angle/zoom, min
7.00 °
beam angle/zoom, max
7.00 °
light source
LED
light source color temperature
6000 K
color temperature, min
6000 K
color temperature, max
6000 K
Number of light sources
32 pcs
wattage per light source
10.00 W
