EUROLITE LED STL-50F COB 5600K

EUROLITE

1
2
3
4

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED STL-50F COB 5600K

Info
order code
41602580
product link
EAN
4026397447934
Product Name
EUROLITE LED STL-50F COB 5600K
technical overview
Power supply: 230 V AC, 50 Hz
DMX channels: 1/3
DMX connection: 3-pin XLR
LED type: Array 50 W
LED number: 1
Color temperature: 5600 K
Beam angle: 7° - 36°
Dimensions (L x W x H): 280 x 240 x 320 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
Weight: 4,5 kg
IP classification: IP20
Beam angle: 7 - 36°
Power consumption: 65,00 W
Lamp type: LED lamp
Height: 28 cm
Width: 24 cm
DMX channels: 1; 3
LED: 1 x COB (chip-on-board) 50 W CW (homogenous color mix)
Power supply: 230 V AC, 50 Hz
main features
Daylight studio lighting with powerful 50 W COB LED
-Compact housing in a beautiful design
-Functions: dimmer, strobe effect, Master/Slave operation
-Mounting bracket for installations on a stand or a crossbeam
-DMX-controlled operation or stand-alone operation
-1 or 3 DMX channels selectable for numerous applications
-DMX512 control possible via any commercial DMX controller
-Manually adjustable zoom
-With color filter frame
-Optional barndoors available
-Different dimmer curves and dimmer speed adjustable
-5600 K color temperature
-Comfortable addressing and setting via Control Board with LCD display and four operating buttons
-Power connection via Neutrik PowerCon jack and included power cable
-Feed-through output allows to power another device
-After every 8 devices, the fixtures must have a renewed connection with the power mains
-Case color: Black
-Projection: flicker-free
-Control: Stand-alone; DMX
-LED: 1 x COB (chip-on-board) 50 W CW (homogenous color mix)
Connectors
DMX connector types
3pin
Control
control channels, min
1 ch
control channels, max
3 ch
Electrical
power consumption watt, max
65.00 W
AC Volts, min
230 V
AC Volts, max
230 V
AC Frequency, min
50 Hz
AC Frequency, max
50 Hz
IP rating
20
Mechanical
weight
4.50 kg
width
240.00 mm
height
320.00 mm
length
280.00 mm
Optical
beam angle/zoom, min
36.00 °
beam angle/zoom, max
7.00 °
light source
LED
light source color temperature
5600 K
color temperature, min
5600 K
color temperature, max
5600 K
Number of light sources
1 pcs
wattage per light source
50.00 W
