EUROLITE Audience Blinder 2xPAR-36 DMX bk

EUROLITE

1
2
3
4

Technical specifications, datasheets, descriptions and tender texts for EUROLITE Audience Blinder 2xPAR-36 DMX bk

Info
order code
42103413
product link
EAN
4026397449525
Product Name
EUROLITE Audience Blinder 2xPAR-36 DMX bk
technical overview
Power supply: 230 V AC, 50 Hz
On-period: 3 minutes
Cooling time: 3 minutes
Dimensions (L x W x H): 155 x 380 x 240 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
DMX channels: 1
Power consumption: 1200 W
Weight: 2,43 kg
Lamp type: Halogen lamp
IP classification: IP20
Height: 24 cm
Depth: 15,5 cm
Width: 38,8 cm
Power connection: Fix Power supply cord with safety plug (M)
Power supply: 230 V AC, 50 Hz
main features
High-quality stage version
-DMX512 control possible via any commercial DMX controller
-1 controllable DMX channel
-Manual dimming via DIP switches
-For 2 PAR 36 120V/650W lamps
-Each lamp is individually connected to an internal lustre terminal, so that any lamps of your choice can easily be wired
-Extreme and lightning-fast light displays
-Rugged housing
-Delivered with silicone power cord and safety-plug
-Ceiling or trussing installation possible
-Case color: Black
-Power connection: Fix Power supply cord with safety plug (M)
-Control: Stand-alone; DMX
Control
control channels, min
1 ch
control channels, max
1 ch
Electrical
power consumption watt, max
1200.00 W
AC Volts, min
230 V
AC Volts, max
230 V
AC Frequency, min
50 Hz
AC Frequency, max
50 Hz
IP rating
20
power input connector
fixed
Mechanical
weight
2.43 kg
width
388.00 mm
height
240.00 mm
length
155.00 mm
Optical
light source
Halogen
