EUROLITE LED CBB-2 COB RGB Bar

EUROLITE

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED CBB-2 COB RGB Bar

Info
order code
51930274
product link
EAN
4026397654776
Product Name
EUROLITE LED CBB-2 COB RGB Bar
technical overview
Power supply: 100-240 V AC, 50/60 Hz
Power consumption: 50 W
DMX channels: 3/4/5/6/11
DMX connection: 3-pin XLR
Sound-control: via built in microphone
QuickDMX connection: USB, type A
LED type: 25 W RGB (COB)
LED number: 2
Beam angle: 38°
Flash rate: 0-20 Hz
Dimensions (L x W x H): 240 x 155 x 175 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
Lamp type: LED lamp
Cooling fan: Yes
IP classification: IP20
Beam angle: 38°
Weight: 2,45 kg
DMX channels: 3; 4; 5; 6; 11
Depth: 24 cm
Height: 17,5 cm
Width: 15,5 cm
LED: 2 x COB (chip-on-board) 30 W 3in1 TCL RGB (homogenous color mix)
main features
LED light effect bar with RGB color mixing, incl. IR remote control
-2 high-power 25 W RGB LEDs (COB)
-Auto, music, master/slave and DMX mode
-Built-in auto and music show programs
-Direct color selection for 18 preset colors
-Stepless RGB color blend, color change, color fade, dimmer and strobe effect
-Addressing and setting via control panel with 4-digit LED display
-Convenient wireless control via included IR remote control EUROLITE IR-7
-Sound-control via built-in microphone with adjustable microphone sensitivity
-Supports QuickDMX - the wireless DMX system from Eurolite
-Built-in phantom-powered USB port for QuickDMX receivers (accessories)
-DMX512 control possible via any commercial DMX controller
-3, 4, 5, 6 or 11 DMX channels selectable for various applications
-Swivel mounting bracket
-Feed-through output allows to power up to 8 devices
-Case color: Black
-Projection: flicker-free
-Control: QuickDMX USB; IR remote control (provided)
-LED: 2 x COB (chip-on-board) 30 W 3in1 TCL RGB (homogenous color mix)
Connectors
DMX connector types
3pin
Control
control channels, min
3 ch
control channels, max
11 ch
Electrical
power consumption watt, max
25.00 W
AC Volts, min
100 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
IP rating
20
cooling
active
Mechanical
weight
2.45 kg
width
155.00 mm
height
175.00 mm
length
240.00 mm
Optical
beam angle/zoom, min
38.00 °
beam angle/zoom, max
38.00 °
light source
LED
Number of light sources
2 pcs
wattage per light source
30.00 W
multichip LED
yes
RED light source
yes
GREEN light source
yes
BLUE light source
yes
shutter/strobe frequency, max
20 Hz
