EUROLITE LED CBB-2 COB WW Bar

EUROLITE

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED CBB-2 COB WW Bar

Info
order code
51930276
product link
EAN
4026397654738
Product Name
EUROLITE LED CBB-2 COB WW Bar
technical overview
Power supply: 100-240 V AC, 50/60 Hz
Power consumption: 50 W
DMX channels: 2/3/5
DMX connection: 3-pin XLR
Sound-control: via built in microphone
QuickDMX connection: USB, type A
LED type: 35 W WW (COB)
LED number: 2
Color temperature: 2700 K
Beam angle: 37°
Flash rate: 0-20 Hz
Dimensions (L x W x H): 240 x 155 x 175 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
Lamp type: LED lamp
Cooling fan: Yes
IP classification: IP20
Beam angle: 37°
Weight: 2,45 kg
Width: 15,5 cm
DMX channels: 2; 3; 5
Height: 17,5 cm
Depth: 24 cm
LED: 2 x COB (chip-on-board) 35 W WW (homogenous color mix)
main features
LED light effect bar with WW COB LEDs, incl. IR remote control
-2 high-power warm white 35 W LEDs (COB)
-Very high color rendering index (CRI >90)
-Auto, music, master/slave and DMX mode
-Built-in auto and music show programs
-Dimmer and strobe effect
-Addressing and setting via control panel with 4-digit LED display
-Convenient wireless control via included IR remote control EUROLITE IR-7
-Sound-control via built-in microphone with adjustable microphone sensitivity
-Supports QuickDMX - the wireless DMX system from Eurolite
-Built-in phantom-powered USB port for QuickDMX receivers (accessories)
-DMX512 control possible via any commercial DMX controller
-2, 3 or 5 DMX channels selectable for various applications
-Swivel mounting bracket
-Feed-through output allows to power up to 8 devices
-Case color: Black
-Projection: flicker-free
-Color rendering index (CRI) more than: 90 Ra
-Control: QuickDMX USB; IR remote control (provided)
-LED: 2 x COB (chip-on-board) 35 W WW (homogenous color mix)
Connectors
DMX connector types
3pin
Control
control channels, min
2 ch
control channels, max
5 ch
Electrical
power consumption watt, max
35.00 W
AC Volts, min
100 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
IP rating
20
cooling
active
Mechanical
weight
2.45 kg
width
155.00 mm
height
175.00 mm
length
240.00 mm
Optical
beam angle/zoom, min
37.00 °
beam angle/zoom, max
37.00 °
light source
LED
light source color temperature
2700 K
color temperature, min
2700 K
color temperature, max
2700 K
Number of light sources
2 pcs
wattage per light source
35.00 W
WARM WHITE LED source
yes
shutter/strobe frequency, max
20 Hz
