EUROLITE LED Bar Rainbow

EUROLITE

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED Bar Rainbow

Info
order code
51930441
product link
EAN
4026397645262
Product Name
EUROLITE LED Bar Rainbow
technical overview
Power supply: 100-240 V AC, 50/60 Hz
DMX channels: 5/8
DMX connection: 3-pin XLR
Sound-control: via built-in microphone
LED type: 3W RGB (3in1)
LED number: 8
Beam angle: 160°
Dimensions (L x W x H): 416 x 86 x 110 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
IP classification: IP20
Power consumption: 20 W
Beam angle: 160°
Weight: 1,18 kg
Lamp type: LED lamp
Length: 41,6 cm
Depth: 8,6 cm
DMX channels: 5; 8
Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M)
Height: 11 cm
LED: 8 x high-power 3 W 3in1 TCL RGB
Power supply: 110-240 V AC, 50/60 Hz
main features
Unique rainbow effect with different color changes and strobe effects
-Special lenses enable the representation of a rainbow with its 7 rainbow colors
-Beam angle in longitudinal direction 160°
-8 high-power 3 W RGB LEDs (3in1)
-Different color changing and color fading programs, dimmer and various strobe effects
-Dimmer speed (step response) adjustable
-Auto, music, master/slave and DMX mode
-Addressing and setting via control panel with 4-digit LED display
-Sound-control via built-in microphone
-DMX512 control possible via any commercial DMX controller
-5 or 8 DMX channels selectable
-Swivel mounting bracket
-Hanging as well as standing installation possible
-Feed-through output to power up to 8 devices
-Ready for connection via enclosed IEC power cord with safety-plug
-Case color: Black
-Effect: Strobe effect
-Projection: flicker-free
-Power out: 1 x IEC connector (F) mounting version
-Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) (provided)
-Control: Stand-alone; DMX
-LED: 8 x high-power 3 W 3in1 TCL RGB
Connectors
DMX connector types
3pin
Control
control channels, min
5 ch
control channels, max
8 ch
Electrical
power consumption watt, max
3.00 W
AC Volts, min
110 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
IP rating
20
power input connector
IEC-60320 C13/C14
Mechanical
weight
1.18 kg
width
86.00 mm
height
110.00 mm
length
60.00 mm
Optical
beam angle/zoom, min
160.00 °
beam angle/zoom, max
160.00 °
light source
LED
Number of light sources
8 pcs
wattage per light source
3.00 W
multichip LED
yes
RED light source
yes
GREEN light source
yes
BLUE light source
yes
