EUROLITE LED Party Panel RGB+UV

EUROLITE

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED Party Panel RGB+UV

Info
order code
42110199
product link
EAN
4026397630749
Product Name
EUROLITE LED Party Panel RGB+UV
technical overview
Power supply: 100-240 V AC, 50/60 Hz
DMX channels: 3/4/4-1/8
DMX connection: 3-pin XLR
Sound-control: via built-in microphone
LED type: 4 W RGB+UV (4in1)
LED number: 9
Flash rate: 0-20 Hz
Dimensions (L x W x H): 51 x 150 x 150 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
Cooling fan: No, cooling by convection
IP classification: IP20
Lamp type: LED lamp
Weight: 0,75 kg
Power consumption: 13 W
Height: 15 cm
Depth: 5,1 cm
Width: 15 cm
Power connection: Fix Power supply cord with Euro plug (M)
DMX channels: 3; 4; 8
LED: 9 x high-power 4 W 4in1 QCL RGB/UV (homogenous color mix)
Power supply: 110-240 V AC, 50/60 Hz
main features
LED party panel with RGB+UV color mixing and DMX
-9 high-power 4 W RGB+UV LEDs (4in1)
-Auto, music, master/slave and DMX mode
-Built-in auto and music show programs
-Direct color selection for 17 preset colors
-Stepless RGB+UV color mixture, color change, color fade, dimmer and strobe effect
-Addressing and setting via control panel with 4-digit LED display
-Convenient wireless control via included IR remote control EUROLITE IR-7
-Sound-control via built-in microphone with adjustable microphone sensitivity
-DMX512 control possible via any commercial DMX controller
-3, 4, 4-1 or 8 DMX channels selectable for various applications
-Swivel mounting bracket
-Additional bracket for floor use
-Case color: Black
-Effect: Strobe effect; UV
-Projection: flicker-free
-Power connection: Fix Power supply cord with Euro plug (M)
-Control: IR remote control (provided); Stand-alone; DMX
-LED: 9 x high-power 4 W 4in1 QCL RGB/UV (homogenous color mix)
Connectors
DMX connector types
3pin
Control
control channels, min
3 ch
control channels, max
8 ch
Electrical
power consumption watt, max
4.00 W
AC Volts, min
110 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
IP rating
20
power input connector
Europlug
cooling
passive
Mechanical
weight
0.75 kg
width
150.00 mm
height
150.00 mm
length
51.00 mm
Optical
light source
LED
Number of light sources
9 pcs
wattage per light source
4.00 W
multichip LED
yes
RED light source
yes
GREEN light source
yes
BLUE light source
yes
UV light source
yes
shutter/strobe frequency, max
20 Hz
