| Info | |
|---|---|
| order code |
51741072
|
| product link | |
| EAN |
4026397598698
|
| Product Name |
EUROLITE LED FE-6 Hybrid Laser Flower
|
| technical overview |
Power supply: 100-240 V AC, 50/60 Hz Laser classification: 3R Laser modules: Red (64 mW, 532 nm), green (54 mW, 650 nm) Color LEDs: 4 (R, G, B, W), 1 W each Strobe LEDs: 8, 1 W each Sound control: via built-in microphone Dimensions (L x W x H): 250 x 180 x 195 mm Laser class: Class 3R Lamp type: LED lamp Cooling fan: Yes IP classification: IP20 Weight: 1,5 kg Power consumption: 32 W Height: 19,5 cm Depth: 18 cm Width: 25 cm Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) LED: 8 x 1 W CW (homogenous color mix); 4 x high-power 1 W RGBW Power supply: 110-240 V AC, 50/60 Hz Laser module: R red 532nm; G green 532nm |
| main features |
Small beamer with mirror ball effect, strobe and 2 RG lasers class 3R -Disco ball with 4 rotating LEDs projects bright colors in your room -8 white strobe LEDs -2 laser diodes project thousands of red and green laser beams -Auto and music mode -Convenient control via IR remote control -Color and running speed independently adjustable for each effect -Built-in fan for effective cooling and long lifetime -Sound-control via built-in microphone with sensitivity control -Mounting bracket -Laser class 3R: requires approval and appointment of a laser safety officer -Case color: Black -Laser color: 2in1 BCL RG -Effect: Multi beam effect; Flower effect; Strobe effect -Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) (provided) -Control: Stand-alone; IR remote control (provided) -LED: 8 x 1 W CW (homogenous color mix); 4 x high-power 1 W RGBW |
| Electrical | |
| power consumption watt, max |
1.00 W
|
| AC Volts, min |
110 V
|
| AC Volts, max |
240 V
|
| AC Frequency, min |
50 Hz
|
| AC Frequency, max |
60 Hz
|
| IP rating |
20
|
| power input connector |
IEC-60320 C13/C14
|
| cooling |
active
|
| Mechanical | |
| weight |
1.50 kg
|
| width |
180.00 mm
|
| height |
195.00 mm
|
| length |
250.00 mm
|
| Optical | |
| light source |
LED
|
| Number of light sources |
8 pcs
|
| wattage per light source |
1.00 W
|
| COLD WHITE LED source |
yes
|
| RED light source |
yes
|
| GREEN light source |
yes
|
| BLUE light source |
yes
|
| Laser class |
3R
|
Collect interesting products in a list and download tender specifications at once
| Downloads |
|---|
| Bedienungsanleitung |
|---|
| 00107317.pdf |
