EUROLITE LED FE-6 Hybrid Laser Flower

EUROLITE

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED FE-6 Hybrid Laser Flower

Info
order code
51741072
product link
EAN
4026397598698
Product Name
EUROLITE LED FE-6 Hybrid Laser Flower
technical overview
Power supply: 100-240 V AC, 50/60 Hz
Laser classification: 3R
Laser modules: Red (64 mW, 532 nm), green (54 mW, 650 nm)
Color LEDs: 4 (R, G, B, W), 1 W each
Strobe LEDs: 8, 1 W each
Sound control: via built-in microphone
Dimensions (L x W x H): 250 x 180 x 195 mm
Laser class: Class 3R
Lamp type: LED lamp
Cooling fan: Yes
IP classification: IP20
Weight: 1,5 kg
Power consumption: 32 W
Height: 19,5 cm
Depth: 18 cm
Width: 25 cm
Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M)
LED: 8 x 1 W CW (homogenous color mix); 4 x high-power 1 W RGBW
Power supply: 110-240 V AC, 50/60 Hz
Laser module: R red 532nm; G green 532nm
main features
Small beamer with mirror ball effect, strobe and 2 RG lasers class 3R
-Disco ball with 4 rotating LEDs projects bright colors in your room
-8 white strobe LEDs
-2 laser diodes project thousands of red and green laser beams
-Auto and music mode
-Convenient control via IR remote control
-Color and running speed independently adjustable for each effect
-Built-in fan for effective cooling and long lifetime
-Sound-control via built-in microphone with sensitivity control
-Mounting bracket
-Laser class 3R: requires approval and appointment of a laser safety officer
-Case color: Black
-Laser color: 2in1 BCL RG
-Effect: Multi beam effect; Flower effect; Strobe effect
-Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) (provided)
-Control: Stand-alone; IR remote control (provided)
-LED: 8 x 1 W CW (homogenous color mix); 4 x high-power 1 W RGBW
Electrical
power consumption watt, max
1.00 W
AC Volts, min
110 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
IP rating
20
power input connector
IEC-60320 C13/C14
cooling
active
Mechanical
weight
1.50 kg
width
180.00 mm
height
195.00 mm
length
250.00 mm
Optical
light source
LED
Number of light sources
8 pcs
wattage per light source
1.00 W
COLD WHITE LED source
yes
RED light source
yes
GREEN light source
yes
BLUE light source
yes
Laser class
3R
