EUROLITE LED PUS-6 Hybrid Laser Beam

EUROLITE

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED PUS-6 Hybrid Laser Beam

Info
order code
51741081
product link
EAN
4026397560817
Product Name
EUROLITE LED PUS-6 Hybrid Laser Beam
technical overview
Power supply: 100-240 V AC, 50/60 Hz
Laser classification: 2M
Laser modules: Red 100 mW, green 30 mW
Wavelength: Red 650 nm, green 532 nm
LEDs:
Flower: 20 x RGBAW, 1 W each
Strobe: 12 x white, 1 W each
DMX channels: 3/13
DMX connection: 3-pin XLR
Sound control: via built-in microphone
Battery/remote control: CR2025 button cell 3 V
Dimensions (L x W x H): 290 x 290 x 180 mm
Laser class: Class 2M
Weight: 3,5 kg
Power consumption: 60 W
Lamp type: LED lamp
IP classification: IP20
Height: 29 cm
Depth: 18 cm
Width: 29 cm
Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M)
DMX channels: 3; 13
LED: 12 x high-power 1 W CW (homogenous color mix); 20 x high-power 1 W RGBWA
Power supply: 110-240 V AC, 50/60 Hz
main features
LED flower, showlaser light effect and strobe
-3-in-1 DMX light effect with red and green laser diodes, LED flower effect and white strobe LEDs
-Convenient control via included IR remote control
-Laser class 2M: does not require additional protective measures or appointment of a laser safety officer
-2 laser diodes project thousands of red and green laser beams
-20 RGBAW LEDs for amazing flower effects
-12 white strobe LEDs
-Auto, music, master/slave and DMX mode
-Built-in auto and music show programs that include all 3 effect units
-Addressing and setting via control panel with 4-digit LED display
-Sound-control via built-in microphone with sensitivity control
-Mounting bracket for flexible wall mounting and ceiling suspension
-When fog is used, this effect becomes especially attractive
-Switch-mode power supply for operation between 100 and 240 volts
-Feed-through output allows to power up to 8 devices
-Case color: Black
-Laser color: 2in1 BCL RG
-Effect: Multi beam effect; Flower effect; Strobe effect
-Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) (provided)
-Power out: 1 x IEC connector (F) mounting version
-Control: IR remote control (provided); Stand-alone; DMX
-LED: 12 x high-power 1 W CW (homogenous color mix); 20 x high-power 1 W RGBWA
Connectors
DMX connector types
3pin
Control
control channels, min
3 ch
control channels, max
13 ch
Electrical
power consumption watt, max
60.00 W
AC Volts, min
110 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
IP rating
20
power input connector
IEC-60320 C13/C14
Mechanical
weight
3.50 kg
width
290.00 mm
height
290.00 mm
length
290.00 mm
Optical
Laser class
2M
COLD WHITE LED source
yes
RED light source
yes
GREEN light source
yes
BLUE light source
yes
AMBER light source
yes
Number of light sources
12 pcs
wattage per light source
1.00 W
RED light source wavelength
650 nm
GREEN light source wavelength
532 nm
RED light source power
0.10 W
GREEN light source power
0.03 W
light source
LED
