EUROLITE LED Laser Derby

EUROLITE

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED Laser Derby

Info
order code
51741086
product link
EAN
4026397614039
Product Name
EUROLITE LED Laser Derby
technical overview
Power supply: 100-240 V AC, 50/60 Hz
Laser classification: 2M
Laser modules: Red 150 mW, green 50 mW
Wavelength: Red 650 nm, green 532 nm
LED: 1 x 4in1 RGBW, 30 W
DMX channels: 13
DMX connection: 3-pin XLR
Sound control: via built-in microphone
Dimensions (L x W x H): 200 x 210 x 220 mm
Laser class: Class 2M
Lamp type: LED lamp
Cooling fan: Yes
IP classification: IP20
Weight: 2 kg
Power consumption: 80 W
Height: 22 cm
Depth: 20 cm
Width: 21 cm
Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M)
DMX channels: 13
LED: 1 x COB (chip-on-board) 30 W 4in1 QCL RGBW
Power supply: 110-240 V AC, 50/60 Hz
main features
Lighting effect with derby and showlaser (laser class 2M)
-DMX light effect with RG laser, rotating LED derby and IR remote control
-1 bright 4in1 RGBW LED (30 W) for striking mirror ball effects
-44 precision lenses fill the room with razor-sharp beams in RGBW colors
-2 laser diodes project hundreds of red and green laser beams
-Auto, music, master/slave and DMX mode
-4 built-in auto and music show programs
-Strobe effect, color change, color fade, direct color selection
-Convenient wireless control via included IR remote control
-Addressing and setting via control panel with 4-digit LED display
-Laser class 2M: does not require additional protective measures or appointment of a laser safety officer
-Sound-control via built-in microphone with sensitivity control
-Metal housing with movable mounting bracket
-Case color: Black
-Laser color: 2in1 BCL RG
-Effect: Multi beam effect
-Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) (provided)
-Control: IR remote control (provided); Stand-alone; DMX
-LED: 1 x COB (chip-on-board) 30 W 4in1 QCL RGBW
Connectors
DMX connector types
3pin
Control
control channels, min
13 ch
control channels, max
13 ch
Electrical
power consumption watt, max
30.00 W
AC Volts, min
110 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
IP rating
20
power input connector
IEC-60320 C13/C14
cooling
active
Mechanical
weight
2.00 kg
width
210.00 mm
height
220.00 mm
length
200.00 mm
Optical
light source
LED
Number of light sources
1 pcs
wattage per light source
30.00 W
multichip LED
yes
COLD WHITE LED source
yes
RED light source
yes
GREEN light source
yes
BLUE light source
yes
RED light source wavelength
650 nm
GREEN light source wavelength
532 nm
RED light source power
0.15 W
GREEN light source power
0.05 W
Laser class
2M
