EUROLITE LED MDB-12 Mini Double Ball

EUROLITE

1
2
3
4

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED MDB-12 Mini Double Ball

Info
order code
51812262
product link
EAN
4026397598667
Product Name
EUROLITE LED MDB-12 Mini Double Ball
technical overview
Power supply: 230 V AC, 50 Hz
via included power unit (12 V AC, 650 mA)
LED number: 6 (1 x R, 1 x G, 1 x B per ball)
Cable length: 1.8 m
Dimensions (L x W x H): 300 x 162 x 185 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
Lamp type: LED lamp
IP classification: IP20
Weight: 1 kg
Power consumption: 8 W
Laser class: Without laser
Height: 18,5 cm
Depth: 16,2 cm
Width: 30 cm
Power connection: Mains Input Socket (M) Coaxial power connector (M) Power supply cord with AC adapter (m)
LED: 6 x RGB
Power supply: 230 V AC, 50 Hz
main features
Simple light effect with rotation around 2 axis with RGB colors
-6 color LEDs (R, G, B) project bright colors in your room
-Double rotation around the horizontal and vertical axis
-Easy plug-and-play operation
-Adds fun to your party rooms and small clubs
-Lightweight plastic housing with handle
-Folding clamp at the bottom
-Low power consumption
-Operation via included power unit
-Case color: Black
-Effect: Multi beam effect
-Power connection: Mains Input Socket (M) Coaxial power connector (M) Power supply cord with AC adapter (m) (provided)
-Control: Stand-alone
-LED: 6 x RGB
Electrical
power consumption watt, max
8.00 W
AC Volts, min
230 V
AC Volts, max
230 V
AC Frequency, min
50 Hz
AC Frequency, max
50 Hz
IP rating
20
external PSU
yes
Mechanical
weight
1.00 kg
width
300.00 mm
height
185.00 mm
length
300.00 mm
Optical
RED light source
yes
GREEN light source
yes
BLUE light source
yes

add to list

Collect interesting products in a list and download tender specifications at once

show list

Videos
Downloads
Bedienungsanleitung
00104028.pdf
