EUROLITE LED FE-19 Flower Effect

EUROLITE

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED FE-19 Flower Effect

Info
order code
51918531
product link
EAN
4026397403695
Product Name
EUROLITE LED FE-19 Flower Effect
technical overview
Power supply: 230 V AC, 50 Hz
Sound-control: via built-in microphone
LED type: 5 mm
LED number: 18
Beam angle: 42°
Dimensions (L x W x H): 210 x 185 x 170 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
Weight: 1 kg
IP classification: IP20
Beam angle: 42°
Power consumption: 28,00 W
Lamp type: LED lamp
Laser class: Without laser
Height: 17 cm
Depth: 21 cm
Width: 18,5 cm
Power connection: Fix Power supply cord with safety plug (M)
LED: 18 x 5 mm RGB
Power supply: 230 V AC, 50 Hz
main features
Simple flower effect with matrix projections
-The colorful flower-beams change their direction of movement at every bass-beat
-Sound-control via built-in microphone
-Microphone-sensitivity adjustable via rotary-control
-Very compact housing
-Ready for connection with power cord and safety-plug
-Innumerable uses: for bands, stages or solo entertainers
-Delivered in a four-color carton
-Case color: Black
-Effect: Flower effect; Multi beam effect
-Power connection: Fix Power supply cord with safety plug (M)
-Control: Stand-alone
-LED: 18 x 5 mm RGB
Electrical
power consumption watt, max
28.00 W
AC Volts, min
230 V
AC Volts, max
230 V
AC Frequency, min
50 Hz
AC Frequency, max
50 Hz
IP rating
20
power input connector
fixed
Mechanical
weight
1.00 kg
width
185.00 mm
height
170.00 mm
length
210.00 mm
Optical
beam angle/zoom, min
42.00 °
beam angle/zoom, max
42.00 °
light source
LED
Number of light sources
18 pcs
RED light source
yes
GREEN light source
yes
BLUE light source
yes
