EUROLITE LED BC-6 Beam Effect

EUROLITE

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED BC-6 Beam Effect

Info
order code
51918806
product link
EAN
4026397500301
Product Name
EUROLITE LED BC-6 Beam Effect
technical overview
Power supply: 100-240 V AC, 50/60 Hz
DMX channels: 9
DMX connection: 3-pin XLR
Sound-control: via built-in microphone
Rotation speed: 10-50
Rotation: 180°
LED type: 1 W
LED number: 2 x red, 1 x green, 1 x blue, 1 x amber, 1 x white
Dimensions (L x W x H): 185 x 185 x 150 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
IP classification: IP20
Power consumption: 14,00 W
Lamp type: LED lamp
Weight: 0,5 kg
Laser class: Without laser
Height: 15 cm
Depth: 18,5 cm
Rotation: 10 RPM to 50 RPM 180 °
Width: 18,5 cm
Power connection: Fix Power supply cord with Euro plug (M)
DMX channels: 9
LED: 6 x high-power 1 W RGBWA
Power supply: 110-240 V AC, 50/60 Hz
main features
Compact mirror ball effect with a radiating plexiglas dome & DMX
-Clear, faceted surface provides for unique beam effects
-Equipped with bright red, green, blue, amber and white LEDs
-10 to 50 rotations (180°) per minute produce circular light plays
-Operable in stand-alone mode or via DMX
-DMX-512 control possible via any commercial DMX-controller (occupies 9 channels)
-Sound-control via built-in microphone
-Comfortable addressing and setting via control panel with 4-digit LED screen and four operating buttons
-Functions: stepless color change; color fade; internal programs; dimmer, strobe settings, motor rotation and speed adjustable via stand-alone mode and via DMX; Master/Slave
-Memory function
-Plastic housing with mounting brackets
-Switch-mode power supply for operation between 100 and 240 volts
-Ready for connection via power cord with safety plug
-Case color: Black
-Effect: Multi beam effect
-Power connection: Fix Power supply cord with Euro plug (M)
-Control: Stand-alone; DMX
-LED: 6 x high-power 1 W RGBWA
Connectors
DMX connector types
3pin
Control
control channels, min
9 ch
control channels, max
9 ch
Electrical
power consumption watt, max
14.00 W
AC Volts, min
110 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
IP rating
20
power input connector
Europlug
Mechanical
weight
0.50 kg
width
185.00 mm
height
150.00 mm
length
185.00 mm
Optical
Number of light sources
6 pcs
wattage per light source
1.00 W
COLD WHITE LED source
yes
RED light source
yes
GREEN light source
yes
BLUE light source
yes
AMBER light source
yes
