EUROLITE LED B-40 HCL Beam Effect

EUROLITE

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED B-40 HCL Beam Effect

Info
order code
51918951
product link
EAN
4026397617702
Product Name
EUROLITE LED B-40 HCL Beam Effect
technical overview
Power supply: 100-240 V AC, 50/60 Hz
DMX control channels: 5/11
DMX512 connection: 3-pin XLR
Sound control: via built-in microphone
LED type: 12 W RGBAW+UV (6in1)
LED number: 5
Flash rate: 0-20 Hz
Dimensions (L x W x H): 320 x 320 x 380 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
Lamp type: LED lamp
Cooling fan: Yes, super silent
IP classification: IP20
Weight: 4 kg
Power consumption: 50 W
Laser class: Without laser
Height: 38 cm
Depth: 32 cm
Width: 32 cm
Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M)
DMX channels: 5; 11
LED: 5 x high-power 12 W 6in1 HCL RGBWA/UV
Power supply: 110-240 V AC, 50/60 Hz
main features
LED beam effect with RGBAW+UV color mixing
-5 high-power 12 W RGBAW+UV LEDs (6in1)
-Precision lenses fill the room with razor-sharp beams in RGBAW+UV colors
-Auto, music, master/slave and DMX mode
-4 built-in auto and music show programs
-Rotation speed variably adjustable
-Direct color selection for 25 preset colors
-Stepless RGBAW+UV color blend, color change, color fade, dimmer and strobe effect
-Addressing and setting via control panel with 4-digit LED display
-Sound-control via built-in microphone with adjustable microphone sensitivity
-DMX512 control possible via any commercial DMX controller
-5 or 11 DMX channels selectable for various applications
-Mounting bracket
-Feed-through output allows to power up to 8 devices
-Case color: Black
-Effect: Multi beam effect; UV
-Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) (provided)
-Power out: 1 x IEC connector (F) mounting version
-Control: Stand-alone; DMX
-LED: 5 x high-power 12 W 6in1 HCL RGBWA/UV
Connectors
DMX connector types
3pin
Control
control channels, min
5 ch
control channels, max
11 ch
Electrical
power consumption watt, max
12.00 W
AC Volts, min
110 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
IP rating
20
power input connector
IEC-60320 C13/C14
cooling
active
Mechanical
weight
4.00 kg
width
320.00 mm
height
380.00 mm
length
320.00 mm
Optical
light source
LED
Number of light sources
5 pcs
wattage per light source
12.00 W
multichip LED
yes
COLD WHITE LED source
yes
RED light source
yes
GREEN light source
yes
BLUE light source
yes
UV light source
yes
AMBER light source
yes
shutter/strobe frequency, max
20 Hz
