EUROLITE LED FL-1500 Flamelight with DMX

EUROLITE

1
2
3

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED FL-1500 Flamelight with DMX

Info
order code
51114412
product link
EAN
4026397550382
Product Name
EUROLITE LED FL-1500 Flamelight with DMX
technical overview
Power supply: 230 V AC, 50 Hz
DMX channels: 3/6
DMX connection: 3-pin XLR
Sound-control: via built-in microphone
LED type: 10 mm
LED number: 168: 48 x red, 60 x green, 60 x blue
Dimensions (L x W x H): 520 x 238 x 345 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
Weight: 10 kg
Power consumption: 145 W
Height: 34,5 cm
Depth: 23,8 cm
Width: 52 cm
Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M)
DMX channels: 3; 6
LED: 168 x 10 mm RGB
Power supply: 230 V AC, 50 Hz
main features
DMX controllable flame effect with LEDs (RGB), flame height 150 cm
-Unbelievably realistic effect
-Flame height 150 cm
-Robust version
-Two fans
-Operable in stand-alone mode or via DMX
-DMX512 control possible via any commercial DMX controller (occupies max. 6 channels)
-3 or 6 DMX channels selectable for various applications
-Sound-control via built-in microphone
-Comfortable addressing and setting via control panel with LED display and four operating buttons
-Functions: color intensity, auto mode, sound control, strobe, speed settings, master/slave
-Equipped with 168 x 10 mm LED
-On/off switch
-Case color: Black
-Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) (provided)
-Control: Stand-alone; DMX
-LED: 168 x 10 mm RGB
Connectors
DMX connector types
3pin
Control
control channels, min
3 ch
control channels, max
6 ch
Electrical
power consumption watt, max
145.00 W
AC Volts, min
230 V
AC Volts, max
230 V
AC Frequency, min
50 Hz
AC Frequency, max
50 Hz
power input connector
IEC-60320 C13/C14
Mechanical
weight
10.00 kg
width
520.00 mm
height
345.00 mm
length
520.00 mm
Optical
RED light source
yes
GREEN light source
yes
BLUE light source
yes

add to list

Collect interesting products in a list and download tender specifications at once

show list

Downloads
Bedienungsanleitung
00095370.pdf
