Info | |
---|---|
order code |
51702057
|
product link | |
EAN |
4026397546972
|
Product Name |
EUROLITE Dynamic Faze 1000 Fazer
|
technical overview |
Power supply: 230 V AC, 50 Hz Output distance: 3 m Warm-up time: 3 min. Output volume: 226 m³/min. Tank capacity: 2.3 l DMX connection: 5-pin and 3-pin XLR Dimensions (L x W x H): 430 x 175 x 385 mm Power consumption: 1000 W Weight: 9 kg IP classification: IP20 Color: Black Height: 38,5 cm Depth: 43 cm Width: 17,5 cm Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) DMX channels: 1 Power supply: 230 V AC, 50 Hz |
main features |
DMX fazer produces fine haze, operates with standard fluid -High-output fazer for clubs and stage applications -Produces fine, translucent haze without nebulizing the room at the same time -Ideal for accentuating light and laser beams -Control via cable remote control or integrated DMX interface -Additional handy transmitter for continuous activation -Comfortable addressing and setting via control panel with LED display and 4 operating buttons -Adjustable timer with interval, duration and output volume -Temperature control via thermo switch -Removable tank, fluid level indication -Low fluid sensor -Fan grille with blue LED illumination, switchable -DMX interface with 3- and 5-pin connectors -Operates on standard waterbased fluid -Metal housing with carrying handle -Smoke-output: ca. 3 m -Case color: Black -Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) (provided) -Control: Wired remote control (provided); DMX; Wireless remote control (provided) |
Connectors | |
DMX connector types |
both 3/5pin
|
Control | |
control channels, min |
1 ch
|
control channels, max |
1 ch
|
*# category-effect | |
output volume |
226 m3/min
|
tank size |
3.00 l
|
Electrical | |
power consumption watt, max |
1000.00 W
|
AC Volts, min |
230 V
|
AC Volts, max |
230 V
|
AC Frequency, min |
50 Hz
|
AC Frequency, max |
50 Hz
|
IP rating |
20
|
power input connector |
IEC-60320 C13/C14
|
Mechanical | |
weight |
9.00 kg
|
width |
175.00 mm
|
height |
385.00 mm
|
length |
430.00 mm
|
Collect interesting products in a list and download tender specifications at once
Downloads |
---|
Bedienungsanleitung |
---|
00092533.pdf |
