EUROLITE LED TBL-10 Barrel Effect
EUROLITE
Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED TBL-10 Barrel Effect
| Info | |
|---|---|
| order code |
51786101
|
| product link | |
| EAN |
4026397574838
|
| Product Name |
EUROLITE LED TBL-10 Barrel Effect
|
| technical overview |
Power supply: 100-240 V AC, 50/60 Hz DMX channels: 8 DMX connection: 3-pin XLR Sound-control: via built-in microphone LED type: 10 W RGBW (4in1) LED number: 1 Dimensions (L x W x H): 150 x 143 x 230 mm Ecodesign regulation: Yes Special product: Not designed for household room illumination Purpose: Show effect lighting Cooling fan: Yes IP classification: IP20 Weight: 1,7 kg Power consumption: 22 W Height: 23 cm Depth: 15 cm Width: 14,3 cm Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) DMX channels: 8 LED: 1 x high-power 10 W 4in1 QCL RGBW Power supply: 110-240 V AC, 50/60 Hz |
| main features |
Very compact mirror effect with 10 W LED in RGBW -Equipped with a 10 W 4in1 RGBW LED -DMX-controlled operation or Stand Alone operation with Master/Slave-function (up to 4 slaves) -DMX control via every standard DMX controller |
| Connectors | |
| DMX connector types |
3pin
|
| Control | |
| control channels, min |
8 ch
|
| control channels, max |
8 ch
|
| Electrical | |
| power consumption watt, max |
10.00 W
|
| AC Volts, min |
110 V
|
| AC Volts, max |
240 V
|
| AC Frequency, min |
50 Hz
|
| AC Frequency, max |
60 Hz
|
| IP rating |
20
|
| power input connector |
IEC-60320 C13/C14
|
| cooling |
active
|
| Mechanical | |
| weight |
1.70 kg
|
| width |
143.00 mm
|
| height |
230.00 mm
|
| length |
150.00 mm
|
| Optical | |
| Number of light sources |
1 pcs
|
| wattage per light source |
10.00 W
|
| multichip LED |
yes
|
| COLD WHITE LED source |
yes
|
| RED light source |
yes
|
| GREEN light source |
yes
|
| BLUE light source |
yes
|
