Power supply: 100-240 V AC, 50/60 Hz
via power unit included in the delivery
Number of control channels: 512
Storable scenes: 32
Storable chases: 32 with 600 steps max.
DMX512/RDM output: 3-pin XLR connector
Available storage media: USB devices (FAT32)
Dimensions (L x W x H): 483 x 130 x 82 mm
Rack installation with 3 U
Power consumption: 2,70 W
Weight: 2,39 kg
IP classification: IP20
Color: Black
Height: 8,9 cm
Depth: 13 cm
Width: 48,3 cm
DMX channels: 512
Power connection: Mains Input Socket (M) Coaxial power connector (M) Power supply cord with AC adapter (m)
Power supply: 110-240 V AC, 50/60 Hz

Controller with color & motion effects (28 fixtures, 18 control channels each)
-DMX controller for DMX light effect units such as moving heads, scanners and LED spot lights with RGBW color mixture
-512 DMX channels can be assigned and inverted as desired to 32 control channels (softpatch)
-For 28 fixtures with 18 control channels each
-USB port for storing program data
-Quick programming thanks to 9 integrated movement patterns and 7 color effects (PAN/TILT position, fade time and running time adjustable)
-32 programmable chases with 100 scenes each can be stored
-Manual, time-controlled or sound-controlled chase running mode
-32 programmable scenes
-2 DMX fixture levels can be controlled, each with up to 18 channels
-16 DMX channel faders
-2 jog wheels for pan/tilt
-Blackout function
-Sound control via built-in microphone
-Backlit LCD (2 x 16 characters)
-RDM support (DMX address setup and identify)
-3-pin XLR connector
-Firmware update via USB
-Desktop console
-Rack installation with 3 units
-Case color: Black
-Housing design: (19") 48,3 cm rack installation
-Height unit: 3 U
-Power connection: Mains Input Socket (M) Coaxial power connector (M) Power supply cord with AC adapter (m) (provided)
-Controller useable for: Controls Moving Lights; Controls DMX effects; Luminaires for white; general mix of colors; Controls KLS in general
-Control: DMX
