EUROLITE DMX LED EASY Operator Deluxe

EUROLITE

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for EUROLITE DMX LED EASY Operator Deluxe

Info
order code
70064574
product link
EAN
4026397622546
Product Name
EUROLITE DMX LED EASY Operator Deluxe
technical overview
Power supply: 100-240 V AC, 50/60 Hz
via included power adapter (9 V/300 mA)
Sound-control: via built-in microphone or RCA input
DMX512 output: 3-pin XLR connector
Dimensions (L x W x H): 260 x 140 x 65 mm
Weight: 1,26 kg
Power consumption: 10 W
IP classification: IP20
Color: Black
Height: 6,5 cm
Depth: 14 cm
Width: 26 cm
DMX channels: 24
Power connection: Mains Input Socket (M) Coaxial power connector (M) Power supply cord with AC adapter (m)
Power supply: 110-240 V AC, 50/60 Hz
main features
Controller for 4 colored LED spotlights or one KLS set with 4 segments
-DMX controller for standard LED spotlights
-Easy operation
-4 LED spotlights or 1 KLS set with 4 fixtures can be controlled
-DMX channels for red, green, blue, amber, white, UV, strobe and master
-9 different modes for the DMX channel sequence selectable
-12 integrated preset programs and 12 user-definable programs (each with up to 12 scenes)
-Auto mode or sound control
-4 color controls with 12 colors each
-4 brightness controls
-Controls for overall brightness, running speed, fade and strobe speed
-Function buttons for Blackout, TAP/Tempo, Auto, Music and Strobe
-Compact desktop console
-Case color: Black
-Housing design: Desktop console
-Power connection: Mains Input Socket (M) Coaxial power connector (M) Power supply cord with AC adapter (m) (provided)
-Controller useable for: Luminaires up to 6 LED colors; Controls KLS classic
-Control: DMX
Control
control channels, min
24 ch
control channels, max
24 ch
Electrical
power consumption watt, max
10.00 W
AC Volts, min
110 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
IP rating
20
external PSU
yes
Mechanical
weight
1.26 kg
width
140.00 mm
height
65.00 mm
length
260.00 mm
color
black
