EUROLITE LED Techno Strobe 500 IR

EUROLITE

1
2
3

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED Techno Strobe 500 IR

Info
order code
52200826
product link
EAN
4026397512953
Product Name
EUROLITE LED Techno Strobe 500 IR
technical overview
Power supply: 230 V AC, 50 Hz
Flash-rate: 1-20 Hz
LED type: 10 mm
LED number: 146 white
Beam angle: 11°
Color temperature: 6800K
Dimensions (L x W x H): 280 x 300 x 210 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
Power consumption: 22 W
Weight: 1,5 kg
Lamp type: LED
Height: 21 cm
Depth: 30 cm
Width: 28 cm
Power connection: Fix Power supply cord with Euro plug (M)
LED: 164 x 10 mm CW (homogenous color mix)
Power supply: 230 V AC, 50 Hz
main features
Compact strobe with 164 x 10 mm LED and adjustable flash freuquency
-Flash frequency and microphone sensitivity adjustable
-Static light dimmable via rotary control
-Sound control via built-in microphone
-With mounting bracket and fixation screws
-146 x 10 mm LED
-Infrared-remote control included in delivery
-Ideal for party-rooms and household use
-Ready for connection via power cord with safety-plug
-Strobe color: White
-Effect: Strobe effect
-Power connection: Fix Power supply cord with Euro plug (M)
-Control: IR remote control; Stand-alone
-LED: 164 x 10 mm CW (homogenous color mix)
Electrical
power consumption watt, max
22.00 W
AC Volts, min
230 V
AC Volts, max
230 V
AC Frequency, min
50 Hz
AC Frequency, max
50 Hz
power input connector
Europlug
Mechanical
weight
1.50 kg
width
300.00 mm
height
210.00 mm
length
300.00 mm
Optical
beam angle/zoom, min
11.00 °
beam angle/zoom, max
11.00 °
light source
LED
Number of light sources
146 pcs
light source color temperature
6800 K
shutter/strobe frequency, max
20 Hz
color temperature, min
6800 K
color temperature, max
6800 K

add to list

Collect interesting products in a list and download tender specifications at once

show list

Downloads
Bedienungsanleitung
00082086.pdf
