EUROLITE LED Strobe SMD 270x5050 6400K

EUROLITE

1
2
3

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED Strobe SMD 270x5050 6400K

Info
order code
52200864
product link
EAN
4026397588477
Product Name
EUROLITE LED Strobe SMD 270x5050 6400K
technical overview
Power supply: 100-240 V AC, 50/60 Hz
Sound-control: via built-in microphone
Flash-rate: 10 Hz
LED type: SMD 5050, white
LED number: 270
Color temperatur: 6400 K
Dimensions (Lx WxH): 53 x 240 x 150 mm
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
Weight: 0,35 kg
Power consumption: 13 W
Lamp type: LED
Height: 15 cm
Depth: 5,3 cm
Width: 24 cm
Power connection: Fix Power supply cord with safety plug (M)
LED: 270 x SMD 5050 CW (homogenous color mix)
Power supply: 110-240 V AC, 50/60 Hz
main features
Compact strobe with 270 powerful SMD LEDs, adjustable flash freuquency
-Equipped with 270 bright cold white SMD 5050 LEDs
-You can choose between sound control and auto-mode
-Sound-control via built-in microphone
-Microphone-sensitivity adjustable via rotary-control
-Flash-rate:10 Hz
-Black plastic housing
-Ready for connection via power cord with euro-plug
-Ideal for party-rooms and household use
-Strobe color: White
-Effect: Strobe effect
-Power connection: Fix Power supply cord with safety plug (M)
-Control: Stand-alone
-LED: 270 x SMD 5050 CW (homogenous color mix)
Electrical
power consumption watt, max
13.00 W
AC Volts, min
110 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
power input connector
fixed
Mechanical
weight
0.35 kg
width
240.00 mm
height
150.00 mm
length
53.00 mm
Optical
light source
LED
light source color temperature
6400 K
Number of light sources
270 pcs
shutter/strobe frequency, max
10 Hz

add to list

Collect interesting products in a list and download tender specifications at once

show list

Downloads
Bedienungsanleitung
00101068.pdf
