EUROLITE LED Super Strobe

EUROLITE

1
2
3
4
5

Technical specifications, datasheets, descriptions and tender texts for EUROLITE LED Super Strobe

Info
order code
52200921
product link
EAN
4026397656138
Product Name
EUROLITE LED Super Strobe
technical overview
Power supply: 100-240 V AC, 50/60 Hz
Power consumption: 75 W
Number of DMX channels: 1/2/3
DMX512 connection: 3-pin XLR
LED type: SMD 5050, cold white
LED number: 480
Beam angle: 120°
Flash rate: 1-20 Hz
Color temperature: 6500 K
Dimensions (L x W x H): 80 x 460 x 255 mm
Weight: 3.8 kg
Ecodesign regulation: Yes
Special product: Not designed for household room illumination
Purpose: Show effect lighting
Weight: 3,8 kg
Height: 25,5 cm
Depth: 8 cm
Width: 46 cm
DMX channels: 1; 2; 3
main features
Strobe with 480 bright SMD 5050 LEDs and DMX
-480 cold white LEDs (SMD 5050) for fast, dynamic strobe effects
-Master/slave and DMX mode
-Flash frequency steplessly adjustable (1-20 Hz)
-Brightness steplessly adjustable (0-100%)
-Addressing and setting via control panel with 4-digit LED display
-DMX512 control possible via any commercial DMX controller
-1, 2 or 3 DMX channels selectable
-Swivel mounting bracket
-Power connection via P-Con jack and included power cable with safety plug
-Feed-through output allows to power up to 8 devices
-Effect: Strobe effect
-Projection: flicker-free
Connectors
DMX connector types
3pin
Control
control channels, min
1 ch
control channels, max
3 ch
Electrical
power consumption watt, max
75.00 W
AC Volts, min
100 V
AC Volts, max
240 V
AC Frequency, min
50 Hz
AC Frequency, max
60 Hz
Mechanical
weight
3.80 kg
width
460.00 mm
height
255.00 mm
length
80.00 mm
Optical
beam angle/zoom, min
120.00 °
beam angle/zoom, max
120.00 °
Number of light sources
480 pcs
light source color temperature
6500 K
shutter/strobe frequency, max
20 Hz
color temperature, min
6500 K
color temperature, max
6500 K

add to list

Collect interesting products in a list and download tender specifications at once

show list

Downloads
Bedienungsanleitung
00121115.pdf
