Info | |
---|---|
product description |
The RTI PIKO G20 OPSL is a compact show laser system ' Made in Germany ' in a durable, dustproof built housing, which is perfectly suitable for challenging show laser applications . 17'500 mW guaranteed output power after optics despite the high power it is possible to reach a maximum scan speed of 60 kpps@8° ILDA due to the fast CT-6210H scanners with RayScan Driver beam accuracy and beam shape are extremely advanced , so these units are suitable for high professional applications green Coherent Taipan OPSL module , which stands out due to beam precision and 20'000 mW power newly developed electronics with calibration capability via a browser interface quality product, made in Germany Robust and dustproof housing, which also makes it possible to use it outdoors without problems This laser system impresses by a guaranteed output power of 17'500 mW . For the green laser source a 530 nm Coherent Taipan OPSL module is used, which stands out due to beam precision . The fast CT-6210H scanners incl. RayScan driver reach a maximum of 60 kpps@8° ILDA and a maximum scan angle of 80° at 35 kpps. By default, the RTI PIKO G20 OPSL is controlled via ILDA and is equipped with a newly developed electronics with calibration capability via a browser interface . In addition, color and scanner settings and other parameters can be configured directly via the browser application by connecting the laser directly via LAN (W-LAN is also possible with a suitable access point). Thanks to the browser interface, it is no longer necessary to operate the laser projector directly on the device (since this is often mounted at a height of several meters). All configurations can be conveniently done via a computer (PC, MAC, Linux), a tablet or a mobile phone. Optionally the system can also be operated via LAN, DMX, SD card or in auto mode. W-DMX and a remote control pad are available on request. On the back of the device, there is an 'ILDA-IN' interface as well as an 'ILDA-Through' to loop through the control signal. The emergency stop signal can also be looped through for several RTI NANO laser systems, which means that only one emergency stop is sufficient for all RTI NANO devices connected to one another. Due to the dustproof housing, the maintenance effort is very low and the device is also suitable for tough touring applications . The very powerful RTI PIKO G20 OPSL is well-suited for show laser applications in indoor as well as in outdoor areas , at concerts, festivals and other large events . Graphics projections and long distance projections are easily possible. The RTI PIKO G20 OPSL is a quality product manufactured in Germany . |
order code |
7640144998752
|
MSRP EUR |
34000.00 EUR
|
Product Name |
RTI PIKO G20 OPSL
|
Connectors | |
total number of ILDA inputs |
1
|
Electrical | |
power consumption watt, max |
500.00 W
|
AC Volts, min |
85 V
|
AC Volts, max |
250 V
|
AC Frequency, min |
50 Hz
|
AC Frequency, max |
60 Hz
|
Mechanical | |
weight |
15.00 kg
|
width |
250.00 mm
|
height |
265.00 mm
|
length |
250.00 mm
|
Optical | |
Laser class |
4
|
total laser output power |
17500 mW
|
laser scan angle |
80.00 °
|
galvo speed |
30.00 kpps
|
laser divergence |
1.00 mrad
|
GREEN light source power |
20.00 W
|
GREEN light source wavelength |
530 nm
|
beam diameter |
3.00 mm
|
