ROBIN 800 LEDWash EU model Standard Version
Robe
Technical specifications, datasheets, descriptions and tender texts for ROBIN 800 LEDWash EU model Standard Version
| Info | |
|---|---|
| product description |
The enhanced ROBIN® 800 LEDWash brings Robe’s patented system for seamless, even and smooth zoom and output of RGBW multichip LED technology a step further. Brighter LED chips and a removable beam shaper module with motorized rotation creates the perfect combination for theatre, TV and other professional applications. The fixture has an incredibly wide zoom range starting at 8 degrees and going up to 63 degrees. Many enhanced features include quiet zoom operation, Beam/Wash zoom mode, virtual colour wheel with calibrated whites, RGBW/CMY colour mixing and more. The touch screen navigation display supports many controlling protocols, status data logging, software updates and other features which are standard in the Robe ROBIN series.
|
| product code |
10070520
|
| order code |
10070520
|
| product link | |
| Connectors | |
| total number of DMX inputs |
1 pcs
|
| total number of DMX outputs |
1 pcs
|
| DMX connector types |
both 3/5pin
|
| total network ports FastEthernet |
1 pcs
|
| built-in Switch |
no
|
| Control | |
| max Dimmer resolution |
16 bit
|
| control channels, min |
11 ch
|
| control channels, max |
38 ch
|
| RDM |
yes
|
| wireless dmx |
yes
|
| protocol-DMX |
both
|
| protocol-Artnet |
input
|
| Electrical | |
| power consumption amps, max |
2.50 A
|
| power consumption watt, max |
430.00 W
|
| AC Volts, min |
100 V
|
| AC Volts, max |
240 V
|
| AC Frequency, min |
50 Hz
|
| AC Frequency, max |
60 Hz
|
| operating temp, min |
-5.00 °C
|
| operating temp, max |
75.00 °C
|
| power input connector |
Powercon
|
| cooling |
active
|
| external PSU |
no
|
| Mechanical | |
| weight |
10.90 kg
|
| width |
342.00 mm
|
| height |
444.00 mm
|
| length |
203.00 mm
|
| pan range |
450 °
|
| tilt range |
300 °
|
| color |
black
|
| truss mountable |
yes
|
| shipping weight |
10.90 kg
|
| recessed installation |
no
|
| Optical | |
| beam angle/zoom, min |
8.00 °
|
| beam angle/zoom, max |
63.00 °
|
| light source |
LED
|
| Number of light sources |
37 pcs
|
| wattage per light source |
15.00 W
|
| optics/projection type |
Washlight
|
| multichip LED |
yes
|
| shutter/strobe frequency, max |
20 Hz
|
| variable/linear frost |
no
|
| color temperature, min |
2700 K
|
| color temperature, max |
8000 K
|
| secondary light source |
none
|
| RED light source |
yes
|
| GREEN light source |
yes
|
| BLUE light source |
yes
|
| prism |
no
|
| separate CTO wheel |
yes
|
| beam angle horizontal |
8 °
|
| beam angle vertical |
63 °
|
